型号 | 层数 | A | B | c | D | E | F | G | H |
SS1550 | 2 | 5763 | 1240 | 5120 | 2383 | 610 | 1500 | 1644 | 1960 |
3 | 5940 | 1750 | 5140 | 2383 | 775 | 1500 | 1680 | 1960 | |
SS1860 | 2 | 6808 | 1350 | 6167 | 2366 | 610 | 1800 | 1964 | 2220 |
3 | 7064 | 1970 | 6167 | 2372 | 775 | 1800 | 1984 | 2220 | |
4 | 7222 | 2470 | 6167 | 2372 | 775 | 1800 | 1984 | 2220 | |
SS2060 | 2 | 6808 | 1350 | 6167 | 2566 | 610 | 2000 | 2164 | 2420 |
3 | 7064 | 1970 | 6167 | 2572 | 775 | 2000 | 2184 | 2420 | |
4 | 7222 | 2470 | 6167 | 2572 | 775 | 2000 | 2184 | 2420 | |
SS2070 | 2 | 7892 | 1510 | 7165 | 2933 | 470 | 2000 | 2164 | 2500 |
3 | 8097 | 2044 | 7165 | 2933 | 470 | 2000 | 2164 | 2500 | |
SS2570 | 2 | 7990 | 1665 | 7190 | 3433 | 470 | 2500 | 2664 | 3000 |
3 | 8912 | 2239 | 7190 | 3433 | 470 | 2500 | 2664 | 3000 | |
SS3075 | 2 | 9080 | 2006 | 7973 | 4031 | 3000 | 3184 | 3510 | |
3 | 9257 | 2505 | 7973 | 4031 | 470 | 3000 | 3184 | 3510 | |
3SS3075P | 3 | 9245 | 2511 | 7974 | 4034 | 470 | 3000 | 3214 | 3720 |
2SS3675 | 2 | 9076 | 2127 | 7974 | 4589 | 470 | 3600 | 3832 | 4304 |
2SS3675P | 2 | 9076 | 2127 | 7974 | 4589 | 470 | 3600 | 3832 | 4304 |
型号 | 宽(mm) | 长(mm) | 面积(m3) | 功率( kw) | 最大给料(mm) | 筛孔尺寸(mm) | 产能(tph) |
SS1550 | 1500 | 5000 | 7.5 | 11/18.5 | 200 | 5-30 40-100 | 50-190 250-620 |
SS1860 | 1800 | 6000 | 10.8 | 18.5/22/30 | 200 | 5-3040-100 | 63-285 380-950 |
SS2060 | 2000 | 6000 | 12 | 18.5/22/30 | 200 | 5-30 40-100 | 70-320 420-1050 |
SS2070 | 2000 | 7000 | 14 | 22/30 | 200 | 5-30 40-100 | 70-320420-1050 |
SS2570 | 2500 | 7000 | 17.5 | 30/37 | 300 | 5-30 40-100 | 90-400 530-1320 |
SS3075 | 3000 | 7500 | 22.5 | 30 2/45 2 | 300 | 5-30 40-80 | 105-480630-1350 |
3SS3075P | 3000 | 7500 | 22.5 | 45 2 | 300 | 5-3040-120 | 118-5300712-1800 |
2SS3675 | 3600 | 7500 | 27 | 45 2 | 300 | 5-30 40 -640 | 40-80850- 1600 |
2SS3675P | 3600 | 7500 | 27 | 45 2 | 300 | 5-3040-120 | 40-640850 -2100 |
