约翰迪尔零件查询600 - AMT PISTON AND CRANKSHAFTEPC John Deere online

广数供应链运营团队, 14 02月, 2025,浏览: 595 次

格莳国际 工程机械 重卡 农机 汽配
Pos. Part No Qty Parts name Comments
1. PT13993 [1]   Piston Ring Kit      STANDARD
1. PT13911 [AR]   Piston Ring Kit      0.25 MM (0.010") OVERSIZE
1. PT13912 [AR]   Piston Ring Kit      0.50 MM (0.020") (NLA) OVERSIZE
2. PT13994 [1]   Piston      STANDARD
2. PT13913 [AR]   Piston      0.25 MM (0.010") OVERSIZE
2. PT13914 [AR]   Piston      0.50 MM (0.020") (NLA) OVERSIZE
3. PT13995 [1]   Piston Pin      NLA
4. PT13893 [2]   Snap Ring
5. PT14004 [1]   Connecting Rod
6. PT14008 [1]   Gear
6. M88487 [1]   Shaft Key      NLA; SUB M77843
7. PT13996 [1]   Gear
7. M88487 [1]   Shaft Key      NLA; SUB M77843
8. RE30565 [1]   Crankshaft
9. R91209 [1]   Key
10. AM106652 [1]   Shim      CONTAINS SHIMS FROM 1.05 MM (0.004") TO 1.70 MM (0.067") THICK
11. M70233 [1]   Bearing      (SUB CH15035)
12. PT14006 [1]   Arm      NLA
13. PT14005 [1]   Lock Washer      NLA
14. PT14037 [2]   Bolt      NLA
15. M800496 [1]   Ball Bearing      (SUB FOR PT14205)
16. PT14007 [1]   Balancer
17. M70233 [1]   Bearing      (SUB CH15035)
18. M88487 [1]   Shaft Key      NLA; SUB M77843
19. PT10382 [1]   Ball Bearing      (SUB M802355)
20. AM116775 [1]   Arm Kit      NLA; NOT ILLUSTRATED; INCLUDES PT14005, PT14006 AND PT14037
