约翰迪尔零件查询600 - AMT FUEL TANK AND LINESEPC John Deere online

广数供应链运营团队, 14 02月, 2025，浏览： 820 次

Pos.	Part No	Qty	Parts name	Comments
1.	RE28090	[1]	Gauge	NLA; ORDER AM143246
1.	AM143246	[1]	Gauge
2.	M95849	[2]	Clamp	(SUB FOR (2) M88514)
3.	14M7166	[1]	Lock Nut	M8
4.	24M7207	[1]	Washer	8.400 X 24 X 2 MM
5.	M149638	[1]	Bushing	FUEL TANK, (SUB FOR M88976 OR M119928)
6.	AM38719	[1]	Hand Operated Valve
7.	RE30297	[1]	Fuel Tank	(SUB FOR R88579)
8.	TY22464	[6]	Clamp	(SUB FOR (6) AR21836)
9.	AM116304	[1]	Fuel Filter	(SUB FOR AM38708, THIS APPLICATION)
10.	........	[1]	Hose	6.35 X 800 MM (1/4" X 31.5") (CUT FROM M88753)
11.	AM109212	[1]	Fuel Pump	(SUB FOR AM101074 OR AM106164)
12.	19M7077	[2]	Cap Screw	M6 X 20
13.	........	[1]	Hose	6.35 X 270 MM (1/4" X 10.6") (CUT FROM M88753 (CARBURETOR TO PUMP))
14.	M121562	[1]	Gasket	(SUB FOR R91428)
15.	R91427	[1]	Cover
16.	19M6614	[2]	Cap Screw	M6 X 12
17.	24H1287	[2]	Washer	9/32" X 5/8" X 0.065"
18.	14M7165	[2]	Lock Nut	M6
19.	........	[1]	Hose	6.35 X 370 MM (1/4" X 14.5") (CUT FROM M88753 (PUMP TO CRANKCASE))
20.	19M7163	[1]	Cap Screw	M8 X 25
21.	........	[1]	Hose	6.35 X 370 MM (1/4" X 14.5") (CUT FROM M88753)
