神钢零件查询(4BD1) - ISUZU DIESEL ENGINE - K904 MARK II EXCAVATORS (1/06-12/07) (01-006) - OIL PAN ND OTHER PARTS Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
326 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VI5131001140 | [1] | PUMP ASM, OIL (-81-5) | |
| 1. | VI5131001251 | [1] | PUMP ASM, OIL (-83-8) | |
| 1. | VI5131001252 | [1] | PUMP ASM, OIL | |
| 1-1. | VI5131001220 | [1] | PUMP ASM, OIL (-82-2) | |
| 1-1. | VI513100138! | [1] | PUMP ASM, OIL | |
| 1-1. | VI5131001382 | [1] | PUMP ASM, OIL | |
| 1-1. | VI5131001210 | [1] | PUMP ASM, OIL (-82-2) | |
| 1-1. | VI5131001371 | [1] | PUMP ASM, OIL | |
| 1-1. | VI5131001372 | [1] | PUMP ASM, OIL | |
| 1-2. | VI8941671170 | [1] | PUMP ASM, OIL | |
| 1-2. | VI5131001230 | [1] | PUMP ASM, OIL (-82-2) | |
| 1-2. | VI5131001390 | [1] | PUMP ASM, OIL | |
| 1-2. | VI5131001391 | [1] | PUMP ASM, OIL | |
| 1-3. | VI5131001500 | [1] | PUMP ASM, OIL (-83-8) | |
| 1-3. | VI5131001501 | [1] | PUMP ASM, OIL | |
| 1-4. | VI5131001361 | [1] | PUMP ASM, OIL | |
| 2. | VI5131130330 | [1] | COVER ASM, OIL PUMP (-82-2) | |
| 2. | VI5131130351 | [1] | COVER ASM, OIL PUMP | |
| 4. | VI9131190220 | [1] | DOWEL, COVER-BODY | |
| 5. | VI5131210100 | [1] | GEAR ASM, PUMP DRIVING (-81-2) | |
| 5. | VI5131210140 | [1] | GEAR ASM, PUMP DRIVING | |
| 7. | VI5131250020 | [1] | GEAR, PUMP DRIVEN | |
| 9. | VI9131190370 | [1] | PIPE, SUCTION OIL PUMP | |
| 9-1. | VI5131190060 | [1] | PIPE, SUCTION OIL PUMP | |
| 10. | VI5131400021 | [1] | PIPE ASM, OIL | |
| 10. | VI8941671180 | [1] | PIPE | KOBPIPE ASM, OIL |
| 12. | VI9095612230 | [1] | GASKET | KOBO-RING, SPACER |
| 12. | VI1096231700 | [1] | O-RING | |
| 13. | VI9131430100 | [1] | FILTER STRAINER | KOBGAUZE, STRAINER |
| 14. | VI5131130161 | [1] | COVER (-82-2) | |
| 14. | VI5131130380 | [1] | COVER | KOBCOVER |
| 14-1. | VI5131130390 | [1] | COVER | |
| 15. | VI5131410120 | [1] | CASE, TOP STRAINER (-82-2) | |
| 15. | VI5131410171 | [1] | CASE | KOBTOP STRAINER |
| 16. | VI9131196080 | [1] | SPACER (-82-2) | |
| 16. | VI1131190020 | [1] | SPACER (-83-10) | |
| 16. | VI1131190010 | [1] | SPACER | |
| 17. | VI5131410020 | [1] | CASE, BOTTOM STRAINER (-82-21) | |
| 17. | VI5131410180 | [1] | CASE | KOBBOTTOM STRAINER |
| 18. | VI9010458000 | [4] | BOLT, CASE-BODY FIX | |
| 18-1. | VI9010458550 | [4] | BOLT, CASE-BODY FIX. | |
| 18-2. | VI9010458650 | [4] | BOLT, CASE-BODY FIX. | |
| 19. | VI9091505080 | [4] | WASHER | KOBWASHER, SPR Superseded by part number: VI0915105080 |
| 20. | VI5098430030 | [1] | BALL | KOBBALL, OIL RELIEF VALVE |
| 22. | VI5095800980 | [1] | SPRING | KOBSPRING, COIL COMP |
| 24. | VI5131650040 | [1] | SPRING SEAT | KOBSEAT, SPRING RELIEF VALVE |
| 26. | VI9081040300 | [1] | PIN | KOBPIN, SPLIT RELIEF VALVE |
| 27. | VI5131230100 | [1] | COUPLING, PINION-SHAFT (-83-8) | |
| 27. | VI1131230160 | [1] | COUPLING | KOBCOUPLING, PINION-SHAFT |
| 30. | VI5131280070 | [1] | PINION, OIL PUMP DRIVING | |
| 30-1. | VI5131280090 | [1] | PINION, OIL PUMP DRIVING | |
| 32. | VI9019110250 | [2] | BOLT | KOBBOLT, SEMS OIL PUMP FIX Superseded by part number: VI0500410250 |
| 36. | VI9131190100 | [1] | COLLAR, OIL PUMP | |
| 37. | VI9019108220 | [2] | BOLT BOLT, STRAINER FIX. | BOLT BOLT, STRAINER FIX. |
| 37-1. | VI9019108160 | [1] | BOLT, STRAINER STAY | |
| 38. | VI8941359440 | [1] | STRAINER ASM, OIL | |
| 38-1. | VI5131400130 | [1] | STRAINER ASM, OIL | |
| 39. | VI1096231700 | [1] | PACKING, O-RING | |
