| 1. | E4NN2A098AA | [1/2] | HOUSING | FORRear Brake Outer Superseded by part number: 83955516 |
| 2. | 83955517 | [1] | HOUSING | FORRear Brake Inner, R.H. |
| 3. | 83955518 | [1] | HOUSING | BASRear Brake Inner, L.H. |
| 4. | 47123297 | [8] | BRAKE DISC,53.4mm ID x 204.75mm OD x 4.9mm Thk | JESDisc Assy., Kevlar (Recommended for Service), Start Year: 01-FEB-03 |
| 4. | 83959970 | [8] | DISC | BASAssy., RBF |
| 5. | 83959971 | [4] | DISC | BASIntermediate, Use With Kevlar and RBF |
| 6. | 83955539 | [2] | BRAKE DISC | BASDisc Assy., Actuating, 18° Ramp, Includes: Ref. 7 thru 11 |
| 7. | 81818856 | [4] | LINK | FORActuating Disc |
| 8. | 82979987 | [12] | BALL,7/8" | CURActuating Disc 7/8" |
| 9. | 84814903 | [8] | SPRING | FORActuating Disc Return |
| 10. | 81818828 | [4] | BOLT | FORPIN, PIVOT, Actuating Disc |
| 11. | 87309 | [4] | JAM NUT,Jam, 1/2"-20, G2 | NHJam, G2, 1/2"-20 |
| 12. | 86513181 | [6/12] | SCREW,Hex, 1/2" - 13 x 4 3/4", Gr 8 | IMOCap, HH, G8, 1/2"-13 x 4-3/4" |
| 12. | 20987 | [8] | BOLT,Hex, 1/2" - 13 x 2 1/2", Gr 8 | MKTCap, HH, G8, 1/2"-13 x 2-1/2", RH Hsg, Less Brakes |
| 13. | 83417087 | [2/4] | STUD,1/2"-13-20 x 7 3/4" | BAS |
| 14. | 86539262 | [2/4] | NUT,1/2"-20, Gr 8 | NH |
| 15. | 81802548 | [2] | PIN | BASRear Brake Torque |
| 16. | 81802586 | [2] | ROD | FORBrake Control, 7/16"-20 x 9 1/4" (Mech Actuator Only) |
| 16. | 81877008 | [2] | ROD | BASBrake Control, Metric M12 x 1.75 x 7.03" |
| 17. | 80755 | [2] | COTTER PIN,1/8" OD x 1" OAL | NHPIN, SPLIT (COTTER), 1/8" x 1" L |
| 18. | 76260S36 | [2] | CLEVIS PIN,5/8" x 1 3/8" L | BASPIN, CLEVIS, 5/8" x 1 3/8" L Superseded by part number: 83928668 |
| 19. | 82037652 | [2] | SEAL | FARAssy., (Except Self-Adjusting Cylinder) |
