现代零件查询HBF15/18T-5 3-SPOOL CONTROL VALVE(OPTION,NEW)EPC Hyundai _现代Hyundai_工程机械

现代零件查询HBF15/18T-5 3-SPOOL CONTROL VALVE(OPTION,NEW)EPC Hyundai

广数供应链运营团队, 14 02月, 2025，浏览： 306 次

Pos.	Part No	Qty	Parts name	Comments
.	32FP-02000	[1]	MAIN CONTROL VALVE	HBF15T-5
.	32FP-02000	[1]	MAIN CONTROL VALVE	HBF18T-5
1.	XKBF-00443	[1]	SECTION-INLET
2.	XKBF-00444	[1]	SECTION-LIFT
3.	XKBF-00445	[1]	SECTION-TILT
4.	XKBF-00446	[1]	SECTION-AUX1
5.	XKBF-00447	[1]	SECTION-OUTLET
6.	XKBF-00302	[1]	RELIEF VALVE ASSY	AUX,HBF15T-5
6.	XKBF-00867	[1]	RELIEF VALVE ASSY	AUX,HBF15T-5
6.	XKBF-00302	[1]	RELIEF VALVE ASSY	AUX,HBF18T-5
6.	XKBF-00867	[1]	RELIEF VALVE ASSY	AUX,HBF18T-5
7.	XKBF-00448	[1]	RELIEF VALVE ASSY	MAIN,HBF15T-5
7.	XKBF-00866	[1]	RELIEF VALVE ASSY	MAIN,HBF15T-5
7.	XKBF-00448	[1]	RELIEF VALVE ASSY	MAIN,HBF18T-5
7.	XKBF-00866	[1]	RELIEF VALVE ASSY	MAIN,HBF18T-5
8.	XKBF-00247	[2]	ROD	HBF15T-5
8.	XKBF-00565	[2]	ROD	HBF15T-5
8.	XKBF-00247	[2]	ROD	HBF18T-5
8.	XKBF-00565	[2]	ROD	HBF18T-5
9.	XKBF-00248	[4]	NUT	HBF15T-5
9.	XKBF-00566	[4]	NUT	HBF15T-5
9.	XKBF-00248	[4]	NUT	HBF18T-5
9.	XKBF-00566	[4]	NUT	HBF18T-5
10.	XKBF-00249	[1]	ROD	HBF15T-5
10.	XKBF-00567	[1]	ROD	HBF15T-5
10.	XKBF-00249	[1]	ROD	HBF18T-5
10.	XKBF-00567	[1]	ROD	HBF18T-5
11.	XKBF-00250	[2]	NUT	HBF15T-5
11.	XKBF-00568	[2]	NUT	HBF15T-5
11.	XKBF-00250	[2]	NUT	HBF18T-5
11.	XKBF-00568	[2]	NUT	HBF18T-5
12.	XKBF-00449	[3]	BRACKET
