| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
M94737
|
[1] |
Wing Nut
|
|
| 2. |
M76264
|
[1] |
Washer
|
|
| 3. |
M89679
|
[1] |
Ejector
|
|
| 4. |
M89678
|
[1] |
End
|
|
| 5. |
M75143
|
[1] |
Wing Nut
|
|
| 6. |
M75144
|
[1] |
Air Filter
|
|
| 7. |
M70165
|
[1] |
O-Ring
|
|
| 8. |
M89677
|
[1] |
Housing
|
|
| 9. |
AM105778
|
[1] |
Air Cleaner
|
|
| 10. |
M95364
|
[1] |
Jet
|
|
| 11. |
W39897
|
[1] |
Support
|
|
| 12. |
37M7464
|
[4] |
Screw
|
|
| 13. |
W41014
|
[1] |
Bracket
|
|
| 14. |
19M7881
|
[2] |
Screw
|
|
| 15. |
14M7166
|
[2] |
Lock Nut
|
|
| 16. |
M121559
|
[1] |
Gasket
|
|
| 17. |
E48497
|
[1] |
Hose Fitting
|
|
| 18. |
W41017
|
[1] |
Air Intake
|
|
| 19. |
12H302
|
[2] |
Lock Washer
|
|
| 20. |
19M7547
|
[2] |
Cap Screw
|
|
| 21. |
TY22470
|
[2] |
Clamp
|
|
| 22. |
W41019
|
[1] |
Hose
|
|
| 23. |
H77698
|
[1] |
Tie Band
|
|
| 24. |
M95849
|
[1] |
Clamp
|
|
| 25. |
AW27239
|
[1] |
Kit
|
|
