| 1. | 81802560 | [1] | LEVER | BASDifferential Lock Operating |
| 2. | C7NN2N059A | [1] | PIN | FORLever to Shaft Locking Superseded by part number: 81816595 |
| 3. | 81803345 | [1] | SHAFT | FORR.A. Differential Lock Lever |
| 4. | 81800480 | [1] | SEAL,21.21mm ID x 29.21mm OD x 5.59mm Thk | BASR.A. Differential Lock Lever Shaft (29.21 mm) O.D. |
| 5. | 81803336 | [1] | FORK | BASRear Axle Differential Lock |
| 5. | 80087308 | [1] | NUT | BASJam, G2, 3/8"-24, Serial Range: Fork-Rail Superseded by part number: 86509310 |
| 6. | 81804978 | [1] | SET SCREW,Hex Hd, 3/8"-24 x .97", Cone Pt | BASRear Axle Differential Lock Fork Hex Hd, 3/8"-24 x .97", Cone Pt |
| 7. | 83955462 | [1] | HOUSING | FORAxle Differential Center, CW, Std |
| 7. | 86575908 | [1] | TRANSMISSION HOUSING | BASHousing, Axle Differential Center, CW |
| 7. | 86517774 | [1] | HOUSING | IMOAxle Differential Center, CCW |
| 7. | E9NN4024EA | [1] | HOUSING | FORAxle Differential Center, CW, Oscillating |
| 7. | E9NN4024JA | [1] | HOUSING | FORAxle Differential, CW, Front Oil Fill |
| 7. | 86531943 | [1] | HOUSING | WINAxle Differential Center, CCW, Oscillating |
| 8. | 21T4022 | [1] | BREATHER | GIDifferential Breather, All Models |
| 9. | 263136 | [1] | MAGNETIC PLUG,Sq. Soc, 3/4"-14 NPTF | NHPLUG, MAGNETIC, Sq. Soc, 3/4"-14 NPTF |
| 12. | 82926957 | [1] | PLUG | ZEDOil Level Used on Oscillating and Front Oil Fill Axles |
| 13. | 81844767 | [1] | PLUG | BAS(Less Differential Lock Shaft) |
