Pos.	Part No	Qty	Parts name	Comments
1.	R91230	[1]	Bolt
2.	R91432	[1]	Bolt
3.	R91227	[1]	Panel	(ENGINE SERIAL NUMBER SHOWN.) (SUB W40616, (2) R93185 AND 24M1754)
3.	R93022	[1]	Panel	(ENGINE SERIAL NUMBER SHOWN FIRST, CHASSIS SERIAL NUMBER SHOWN SECOND.) (SUB W40616)
3.	W40616	[1]	Panel	(CHASSIS SERIAL NUMBER SHOWN.)
4.	19M8425	[3]	Cap Screw	M6 X 16
5.	M78945	[1]	Spring	(SUB FOR R91431)
6A.	R91223	[1]	Lever	(CHASSIS SERIAL NUMBER SHOWN.) (SUB W40223 AND 21M7230)
6B.	W40223	[1]	Lever	(CHASSIS SERIAL NUMBER SHOWN.)
7.	W40134	[1]	Washer
8.	R91433	[1]	Bolt	(SUB FOR W40223, AND 21M7230, THIS APPLICATION)
9.	14M7272	[2]	Nut	(CHASSIS SERIAL NUMBER SHOWN.) M6 (USE WITH R93022 OR R91227) (NOT USED WITH W40616)
10.	PT14033	[1]	Spring	(ENGINE SERIAL NUMBER SHOWN.) (NLA) (13 COILS)
10.	R93021	[1]	Spring	(ENGINE SERIAL NUMBER SHOWN.) (NLA) (17 COILS)
11.	PT14032	[1]	Arm
12.	19M8425	[1]	Cap Screw	M6 X 16
13.	19M7933	[1]	Cap Screw	M6 X 25
14.	R91219	[1]	Arm
15.	R91220	[1]	Link	(NLA)
16.	PT14017	[1]	Spring	(NLA)
17.	24M7096	[1]	Washer	(ENGINE SERIAL NUMBER SHOWN.) 10.500 X 18 X 1.600 MM
18.	R93185	[2]	Washer	(ENGINE SERIAL NUMBER SHOWN.)
19.	21M7230	[1]	Screw	M4 X 14
