久保田零件查询T01100 INLET MANIFOLD ENGINEEPC Kubota online
广数供应链运营团队, 14 02月, 2025，浏览：
363 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 010. |
1572711760
|
[1] |
MANIFOLD INLET
|
1.3200(lbs); 0.600
|
| 020. |
1526111820
|
[1] |
GASKET IN-MANIFOLD
|
0.0000(lbs); 0.000
|
| 020. |
1526311820
|
[1] |
GASKET IN-MANIFOLD
|
0.0022(lbs); 0.001
|
| 030. |
1526111830
|
[2] |
GASKET IN-MANIFOLD
|
0.0000(lbs); 0.000
|
| 030. |
1526311830
|
[2] |
GASKET IN-MANIFOLD
|
0.0022(lbs); 0.001
|
| 040. |
0102350620
|
[4] |
BOLT
|
0.0132(lbs); 0.006
|
| 050. |
0105350660
|
[1] |
BOLT
|
0.0308(lbs); 0.014
|
| 060. |
1538191070
|
[1] |
BOLT
|
0.0352(lbs); 0.016
|
| 070. |
0451260060
|
[2] |
WASHER SPRING
|
0.0022(lbs); 0.001
|
