约翰迪尔零件查询600 - AMT DIRECTION INDICATOR LIGHT KITEPC John Deere online

广数供应链运营团队, 14 02月, 2025，浏览： 350 次

Pos.	Part No	Qty	Parts name	Comments
1.	M43835	[6]	Electrical Connector Assy
2.	12M6680	[2]	Lock Washer	12.500 MM
3.	24H1748	[2]	Washer	1/2" X 1-1/4" X 0.105"
4.	14M7459	[2]	Nut	M10
5.	24M7028	[2]	Washer	10.500 X 20 X 2 MM
6.	........	[2]	Holder
7.	........	[2]	Bulb
8.	........	[2]	Gasket
9.	........	[2]	Lens
10.	........	[4]	Screw
11.	AW26910	[2]	Turn Signal Lamp	(FRONT)
12.	........	[1]	Boot	(ORDER AW26912)
13.	R77476	[1]	Electrical Connector Assy
14.	T28585	[5]	Electrical Connector Assy
15.	AW26912	[1]	Switch	(INCLUDES M43835 AND R77476)
16.	AU41465	[1]	Flasher
17.	37H129	[6]	Screw
18.	T29417	[1]	Bracket	(FLASHER MOUNTING)
19.	AW26875	[1]	Wiring Harness	(INCLUDES (2) U46370 AND T28585)
20.	14H1026	[8]	Nut	0.138"
21.	T28586	[1]	Electrical Connector Assy
22.	AW26877	[1]	Wiring Harness	(INCLUDES (4) T28585 AND T28586)
23.	21H1308	[8]	Screw	0.138" X 3/8"
24.	........	[4]	Screw
25.	........	[2]	Lens
26.	W40750	[2]	Gasket
27.	AD2062R	[2]	Bulb	(GE 1156)
28.	........	[2]	Holder
29.	AW26898	[2]	Turn Signal Lamp	(REAR)
30.	12H353	[8]	Lock Washer	0.138"
31.	W40603	[2]	Bracket
32.	12H353	[8]	Lock Washer	0.138"
...	R44302	[10]	Tie Band	4.5 X 185 MM (0.18" X 7.3")
...	AW26904	[1]	Kit	(DIRECTION INDICATOR KIT INCLUDES ALL PARTS LISTED ON THIS PAGE AND INSTALLATION INSTRUCTIONS)
