现代零件查询HBF15/18T-5 DRIVE UNITEPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
648 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
81FY-30100
|
[1] |
DRIVE UNIT ASSY-LH
|
|
| . |
81FY-30200
|
[1] |
DRIVE UNIT ASSY-RH
|
|
| 1. |
ZGAP-00003
|
[1] |
HOUSING
|
|
| 2. |
ZGAP-00004
|
[1] |
CARRIER-IN/DISC
|
|
| 3. |
ZGAP-00005
|
[1] |
GEAR-INTERNAL
|
|
| 4. |
ZGAP-00006
|
[3] |
GEAR-PLANET
|
|
| 5. |
ZGAP-00007
|
[1] |
OTK-SHIM
|
|
| 6. |
ZGAP-00008
|
[1] |
PALTE-FIXING
|
|
| 7. |
ZGAP-00009
|
[5] |
BOLT-WHEEL
|
|
| 8. |
ZGAP-00010
|
[1] |
FILTER-BREATHER
|
|
| 9. |
ZGAP-00011
|
[1] |
FEY-RING
|
|
| 10. |
ZGAP-00012
|
[3] |
CYLINDRICAL R/BEARING
|
|
| 11. |
ZGAP-00013
|
[1] |
GAMMA-RING
|
|
| 12. |
ZGAP-00014
|
[10] |
TORX SOCKET HD SCREW
|
|
| 13. |
ZGAP-00015
|
[1] |
NILOS-RING
|
|
| 14. |
ZGAP-00016
|
[2] |
PLUG-W/MAGNET
|
|
| 15. |
ZGAP-00017
|
[2] |
RING-SEAL
|
|
| 16. |
ZGAP-00018
|
[6] |
SCREW-HEX
|
|
| 17. |
ZGAP-00019
|
[8] |
TORX SCREW
|
|
| 18. |
ZGAP-00020
|
[2] |
CYLINDER PIN
|
|
| 19. |
ZGAP-00021
|
[1] |
CIRCLIP
|
|
| 20. |
ZGAP-00022
|
[1] |
NEEDLE RING
|
|
| 21. |
ZGAP-00023
|
[2] |
TAPER ROLLER BEARING
|
|
| 22. |
ZGAP-00024
|
[1] |
GROOVED BALL BEARING
|
|
| 23. |
ZGAP-00025
|
[3] |
PRESSURE SPRING
|
|
| 24. |
ZGAP-00026
|
[1] |
HOUSING COVER
|
|
| 25. |
ZGAP-00027
|
[1] |
BRAKE LEVER,COMPLETE
|
|
| 26. |
ZGAP-00028
|
[4] |
OUTER CLUTCH DISC
|
|
| 27. |
ZGAP-00029
|
[3] |
INNER CLUTCH DISC
|
|
| 28. |
ZGAP-00030
|
[1] |
AXIAL BEARING
|
|
| 29. |
ZGAP-00031
|
[1] |
PRESSURE DISC
|
|
| 30. |
ZGAP-00032
|
[1] |
PRESSURE PIN OTK
|
|
| 31. |
ZGAP-00033
|
[1] |
PRESSURE DISC OTK
|
|
| 32. |
ZGAP-00034
|
[1] |
CYLINDER PIN
|
|
| 33. |
ZGAP-00035
|
[1] |
SHAFT SEAL
|
|
| 34. |
ZGAP-00036
|
[1] |
PLANET CARRIER ASSY
|
|
| N34-1. |
@
|
[1] |
WHEEL SHAFT
|
|
| N34-2. |
@
|
[1] |
PLANET CARRIER
|
|
| N34-3. |
@
|
[1] |
SLOTTED NUT
|
|
| 34-4. |
ZGAP-00040
|
[1] |
SHAFT SEAL
|
|
| 34-4. |
ZGAP-00082
|
[1] |
SHAFT SEAL
|
|
| 35. |
ZGAP-00041
|
[1] |
PINION
|
|
| 36. |
ZGAP-00042
|
[1] |
SPUR GEAR
|
|
