卡特零件查询（725） 231-5889: DRIVE GP-ACCESSORY
广数供应链运营团队, 14 02月, 2025，浏览：
1005 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 197-9642 | [1] | PULLEY AS-IDLER(8-GROOVE) | |
| 2. | 211-7895 | [1] | BELT TENSIONER(ACCESSORY DRIVE) | |
| 3. | 222-2899 | [1] | BRACKET-SUPPORT | |
| 4. | 227-8313 | [1] | PULLEY AS-IDLER(8-GROOVE) | |
| 5. | 243-1557 | [1] | BRACKET | |
| 6. | 5P-8245 | [4] | WASHER-HARD(13.5X25.5X3-MM THK) | |
| 7. | 6V-2317M | [2] | BOLT(M8X1.25X30-MM) | |
| 8. | 6V-5839 | [3] | WASHER(11X21X2.5-MM THK) | |
| 9. | 6V-5842M | [3] | BOLT(M10X1.5X40-MM) | |
| 10. | 6V-8149M | [2] | NUT(M12X1.75-THD) | |
| 11. | 8T-0646M | [2] | BOLT(M12X1.75X110-MM) | |
| 12. | 8T-4121 | [1] | WASHER-HARD(11X21X2.5-MM THK) | |
| 13. | 8T-4178M | [1] | BOLT(M10X1.5X90-MM) | |
| 14. | 9M-1974 | [2] | WASHER-HARD(8.8X16X2-MM THK) | |
| | M | | METRIC PART |
