神钢零件查询(4BD1) - ISUZU DIESEL ENGINE - K905 MARK II EXCAVATORS (1/06-12/07) (01-004) - FLY WHEEL HOUSING & OTHER PARTS Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
739 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VI5113410073 | [1] | HOUSING, FLY WHEEL (-80-11) | |
| 1. | VI5113410074 | [1] | HOUSING, FLY WHEEL | |
| 1-1. | VI9113416331 | [1] | HOUSING, FLY WHEEL | |
| 1-1. | VI9113416182 | [1] | HOUSING, FLY WHEEL | |
| 1-3. | VI9113418093 | [1] | HOUSING, FLY WHEEL | |
| 1-5. | VI5113410367 | [1] | HOUSING, FLY WHEEL | |
| 1-6. | VI5113410590 | [1] | HOUSING, FLY WHEEL | |
| 1-8. | VI5113411191 | [1] | HOUSING, FLY WHEEL | |
| 1-9. | VI8941710150 | [1] | HOUSING, FLY WHEEL | |
| 2. | VI9944112330 | [3] | STUD | KOBSTARTER FIX. Superseded by part number: VI9944112350 |
| 2-1. | VI9944112330 | [2] | STUD | KOBSTARTER FIX. Superseded by part number: VI9944112350 |
| 3. | VI9910664500 | [6] | BOLT, HOUSING FIX. | |
| 3-1. | VI9910664500 | [2] | BOLT, HOUSING FIX. | |
| 3-2. | VI9910664500 | [8] | BOLT, HOUSING FIX. | |
| 3-6. | VI9910664450 | [2] | BOLT, HOUSING FIX. | |
| 3-7. | VI9910564500 | [2] | BOLT, HOUSING FIX. | |
| 3-8. | VI9910564650 | [4] | B0LT, H0USIN6 FIX. | |
| 5. | VI9096510690 | [6] | WASHER, PL. | |
| 5-1. | VI9091505140 | [6] | WASHER | KOBWASHER, SPR. Superseded by part number: VI9091506140 |
| 5-2. | VI9096510690 | [8] | WASHER, PL. | |
| 6. | VI9992023160 | [1] | PLUG | KOBPLUG, DRAIN Superseded by part number: VI0920024160 |
| 7. | VI9095714160 | [1] | SEAL | KOBPACKING, DRAIN PLUG |
| 8. | VI5096250520 | [1] | O-RING | KOBSEAL, OIL, CRANK REAR Superseded by part number: 5096250520 |
| 8. | VI1096253620 | [1] | HALF-GASKET | KOBSEAL, OIL, CRANK REAR Superseded by part number: 1096253620 |
| 9. | VI9019108250 | [7] | BOLT | KOBFLYWHEEL HOUSING Superseded by part number: VI0505408250 |
| 9-1. | VI9910564650 | [4] | BOLT, FLYWHEEL HOUSING | |
| 9-2. | VI9910664650 | [2] | BOLT, FLYWHEEL HOUSING | |
| 15. | VI9113491340 | [1] | COVER | KOBTIMING CHECK HOLE Superseded by part number: VI9113491341 |
| 16. | VI9113498030 | [1] | COVER, DUST FLYWHEEL | |
| 16. | VI8941145770 | [1] | COVER, OUST FLYWHEEL | |
| 17. | VI9020506120 | [3] | BOLT, DUCT COVER FIX. | |
| 18. | VI9091505060 | [3] | WASHER | KOBWASHER, SPR |
| 19. | VI9992023200 | [1] | PLUG | KOBSTARTER CHECK HOLE |
| 20. | VI9095714200 | [1] | PACKING, CHECK HOLE PLUG | |
| 21. | VI9123631460 | [1] | SPACER, OIL SEAL | |
| 23. | VI5093330350 | [1] | GROMMET, DRAIN PLUG | |
