Pos.	Part No	Qty	Parts name	Comments
1.	81FY-50010	[1]	STEERING AXLE ASSY	HBF15T-5
1.	81FY-50011	[1]	STEERING AXLE ASSY	HBF15T-5
1.	81FY-50010	[1]	STEERING AXLE ASSY	HBF18T-5
1.	81FY-50011	[1]	STEERING AXLE ASSY	HBF18T-5
1-1.	B51410012	[1]	STEERING AXLE WA
1-2.	B51410051	[1]	BRACKET-S/AXLE
1-3.	B51410060	[1]	BEARING-TAPER ROLLER
1-4.	B51410070	[1]	BEARING-TAPER ROLLER
1-5.	B51410080	[1]	SEAL-OIL
1-6.	B51410090	[2]	SEAL-OIL
1-7.	B51410100	[2]	BEARING-TAPER ROLLER
1-8.	FAD0500210	[2]	BEARING-TAPER ROLLER
1-9.	B51410111	[2]	HUB-STEER AXLE
1-10.	S403-301006	[2]	WASHER-PLAIN
1-11.	S461-500502	[2]	PIN-SPLIT
1-12.	B51410120	[10]	BOLT-HUB
1-13.	FAD0500230B	[2]	CAP
1-14.	B51410142	[1]	GEAR 2-STEER	HBF15T-5
1-14.	B51410143	[1]	STEERING GEAR ASS'Y	HBF15T-5
1-14.	B51410142	[1]	GEAR 2-STEER	HBF18T-5
1-14.	B51410143	[1]	STEERING GEAR ASS'Y	HBF18T-5
1-14-2.	81FY-50020	[2]	PIN-STOPPER	HBF15T-5
1-14-2.	81FY-50020	[2]	PIN-STOPPER	HBF18T-5
1-14-3.	S411-160002	[2]	WASHER-SPRING	HBF15T-5
1-14-3.	S411-160002	[2]	WASHER-SPRING	HBF18T-5
1-14-4.	S205-160002	[2]	NUT-HEX	HBF15T-5
1-14-4.	S205-160002	[2]	NUT-HEX	HBF18T-5
2.	S017-140506	[4]	BOLT-HEX
3.	S411-140006	[4]	WASHER-SPRING
4.	S471-600634	[2]	PIN-SPRING
5.	S471-920364	[2]	PIN-SPRING	HBF15T-5
5.	S471-920364	[2]	PIN-SPRING	HBF18T-5
6.	B51410160	[1]	GEAR 1-STEER
7.	F23600280	[1]	SPECIAL WASHER
8.	S035-082526	[1]	BOLT-W/WASHER
10.	B51410190	[1]	LEVER
11.	S015-050256	[1]	BOLT-HEX
12.	S411-050006	[1]	WASHER-SPRING
13.	S403-052006	[1]	WASHER-PLAIN
14.	S203-051006	[1]	NUT-HEX
15.	B51410180	[1]	BRACKET
16.	S109-120556	[2]	BOLT-SOCKET
17.	S411-120006	[2]	WASHER-SPRING
18.	B51410151	[1]	NUT-CASTLE
19.	FAD0500220	[2]	NUT-SLOT
