凯斯零件查询(3440) - CASE IH ROUND BALER (1/87-12/87) (58) - SAFETY CHAIN Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
317 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
100682C3
|
[1] |
CHAIN (AG)
|
IH
CHAIN ASSEMBLY - safety, 5/16 link x 59-1/4 inch (8 x 1 504 MM)
|
| 1. |
148558C1
|
[1] |
CLEVIS
|
IH
- safety chain Superseded by part number: 1279163C1
|
| 2. |
271729
|
[1] |
BOLT,Hex, 5/8" - 11 x 3 1/2", Gr 5
|
IH
- hex, 5/8 NC x 3-1/2 inch Superseded by part number: 413-1056, 413-1056, NLS
|
| 3. |
231-14410
|
[1] |
NUT,5/8"-11, GB
|
CAS
NUT, LOCK, 5/8"-11, GB Superseded by part number: 86639566
|
| 4. |
80280173
|
[1] |
BOLT,Hex, 3/4" - 10 x 2 3/4", Gr 5
|
IMO
- hex, 3/4 NC x 2-3/4 inch
|
| 5. |
26512R1
|
[1] |
WASHER
|
IH
- flat, 25/32 x 2 x 5/32 inch (20 x 51 x 4 MM) Superseded by part number: 86624159
|
| 6. |
22244R1
|
[1] |
LOCK NUT
|
IH
- hex lock, 3/4 inch NC Superseded by part number: 86754
|
| 7. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
PIN - clevis
|
| . . |
61913C92
|
[1] |
PACKAGE
|
IH
KIT - hardware, safety chain, Includes: Ref. 1, 2, 3, 4, 5 and 6 Superseded by part number: 495-81047, 413-1056, 413-1244, 231-14412, 231-14110, 148558C1
|
| 15. |
119354C1
|
[1] |
JACK
|
IH
ASSEMBLY - side crank (Alternate part is 135061C91), parking
|
| 15. |
135061C91
|
[1] |
JACK
|
IH
ASSEMBLY - side crank (Alternate part is 119354C1), parking Superseded by part number: 119354C1
|
