神钢零件查询(4BD1) - ISUZU DIESEL ENGINE - K905 MARK II EXCAVATORS (1/06-12/07) (01-019) - ENGINE ACCESSORY PARTS Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
237 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 50. | VI9839101010 | [1] | ELBOW ASM. | |
| 50. | VI9839101011 | [1] | ELBOW | KOBASM. |
| 50-1. | VI5193100040 | [1] | ELBOW ASM. | |
| 52. | VI5858600011 | [1] | DRIVE ASM, TACHOMETER | |
| 55. | VI9099206470 | [1] | PACKING, O-RING, ELBOW | |
| 55-1. | VI9099205760 | [1] | PACKING, O-RING, ELBOW | |
| 58. | VI1831270030 | [1] | SENSOR ASM, TACHO | |
| 60. | VI9019108200 | [2] | BOLT, SEMS, ELBOW | |
| 60-1. | VI9019708220 | [3] | BOLT, SEMS, ELB0W | |
| 65. | VI8944384720 | [1] | BRACKET, MOTOR STOPPER | |
| 66. | VI9019708180 | [2] | BOLT, BRKT-IN/MANI.FIX. | |
