凯斯零件查询(3450) - CASE IH ROUND TIE BALER (1/83-12/89) (28) - TAILGATE FRAME Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
532 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
ZA104652
|
[1] |
GUIDE
|
IH
TAILGATE
|
| 2. |
ZA105196
|
[1] |
PRODUCT GRAPHIC
|
IH
DECAL - warning
|
| 3. |
ZA740950
|
[1] |
DECAL
|
CAS
- warning Superseded by part number: ZA211862
|
| 4. |
ZA105194
|
[2] |
PRODUCT GRAPHIC
|
IH
DECAL - warning
|
| 5. |
NSS
|
[2] |
NOT SOLD SEPARAT
|
CON
DECAL - important (Order kit 1265869C93)
|
| 7. |
ZA104923
|
[1] |
WEDGE
|
IH
- left
|
| 8. |
ZA104924
|
[1] |
WEDGE
|
IH
- right
|
| 9. |
180122
|
[4] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
IH
- hex, 3/8 NC x 1 inch Superseded by part number: 113-207
|
| 10. |
ZA104715
|
[1] |
PLATE
|
IH
|
| 11. |
17351R1
|
[2] |
CARRIAGE BOLT,Short Sq Nk, 3/8" - 16 x 1", Gr 2
|
IH
BOLT - round head square neck, 3/8 NC x 1 inch Superseded by part number: 88682
|
| 12. |
ZA104716
|
[1] |
STRAP
|
IH
- rubber
|
| 13. |
180124
|
[2] |
BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5
|
IH
- hex, 3/8 NC x 1-1/4 inch Superseded by part number: 88011
|
| 14. |
118775
|
[2] |
WASHER,3/8" x 13/16" x .065"
|
IH
- flat, 13/32 x 13/16 x 3/64 inch (10 x 20 x 1 mm) Superseded by part number: 87613282
|
| 15. |
ZA105505
|
[1] |
GUARD
|
IH
- left
|
| 16. |
ZA104781
|
[1] |
PRODUCT GRAPHIC
|
IH
DECAL - danger
|
| 17. |
ZA105504
|
[1] |
GUARD
|
IH
- right
|
| 18. |
ZA104782
|
[1] |
PRODUCT GRAPHIC
|
IH
DECAL - warning
|
| 19. |
ZA704673
|
[2] |
SPACER
|
IH
|
| 20. |
120390
|
[2] |
WASHER,1/2"
|
IH
- flat, 17/32 x 1-3/8 x 3/32 inch (13 x 34 x 2 mm) Superseded by part number: 106265
|
| 21. |
9413956
|
[2] |
LOCK NUT,1/2"-13, GB
|
IH
NUT - hex, 1/2 inch NC Superseded by part number: 231-4138
|
| 22. |
180181
|
[2] |
BOLT,Hex, 1/2" - 13 x 2", Gr 5
|
IH
- hex, 1/2 NC x 2 inch Superseded by part number: 9706716
|
| 24. |
436525C1
|
[1] |
RIVET,Pop, 1/4" x 1/2"
|
IH
- mandrel, 6.3 x 12.7 mm
|
| 25. |
ZA104865
|
[2] |
BRACKET
|
IH
- light (Prior to P.I.N. 001132)
|
