神钢零件查询(4BD1) - ISUZU DIESEL ENGINE - K905 MARK II EXCAVATORS (1/06-12/07) (01-041) - TURBO CHARGER (NIPPON GARRETT) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
1018 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | VI8944163510 | [1] | TURBOCHARGER | KOBTURBO CHARGER ASM, (RHB 6A) Superseded by part number: 8944183200 |
| . . | VI8944183200 | [1] | TURBOCHARGER | KOBTURBO CHARGER ASM, (RHB 6A) Superseded by part number: 8944183200 |
| 1. | VI8944288960 | [1] | WHEEL ASH , TURBINE | |
| 2. | VI8944288970 | [1] | THROWER, OIL | |
| 3. | VI5144590040 | [1] | BUSH, THRUST | |
| 4. | VI5144550020 | [1] | SEAL, RING BLOWER | |
| 5. | VI1144530220 | [1] | SEAL.RING BLOWER | |
| 6. | VI5144550030 | [1] | SEAL, RING TURBINE | |
| 7. | VI5144590150 | [1] | NUT, LOCK | |
| 8. | VI8944288990 | [1] | PLATE, SEAL | |
| 9. | VI8944289000 | [2] | JOURNAL.BEARING | |
| 10. | VI5144530040 | [1] | METAL,THRUST | |
| 11. | VI5144110040 | [1] | HOUSING, COMPRESSOR | |
| 12. | VI8944101520 | [6] | BOLT | |
| 13. | VI5144290070 | [3] | PLATE, LOCK | |
| 14. | VI5144510030 | [1] | IMPELLER | |
| 15. | VI8944289020 | [1] | HOUSING, TURBINE | |
| 16. | VI5144590170 | [4] | BOLT | |
| 17. | VI8944289030 | [2] | WASHER, LOCK | |
| 18. | VI8944289040 | [1] | HOUSING, BEARING | |
| 19. | VI5144550040 | [4] | RETAINING, RING | |
| 20. | VI5144590110 | [4] | SCREW | |
| 21. | VI5144590120 | [4] | WASHER | |
| 22. | VI5144590130 | [4] | SCREW | |
| 23. | VI5144590140 | [4] | WASHER | |
| 24. | VI8944289050 | [1] | PROTECTOR, HEAT | |
