凯斯零件查询(3450) - CASE IH ROUND TIE BALER (1/83-12/89) (64) - PICKUP, PRIOR TO P.I.N. 001280 Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
408 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 35. |
1281010C1
|
[2] |
BUSHING
|
IH
|
| 36. |
668902R1
|
[1] |
BELT
|
IH
- Speed up (Used with sheave ZA104645) (Interchangeable with ZA104774)
|
| 36. |
ZA104774
|
[1] |
BELT
|
IH
- Slow down (Used with sheave ZA104842) (Interchangeable with 668902R1)
|
| 37. |
ZA104375
|
[1] |
PULLEY
|
IH
SHEAVE AND SPROCKET ASSEMBLY
|
| 38. |
ZA104443
|
[1] |
SHAFT
|
IH
- pivot left
|
| 39. |
152450R1
|
[1] |
SNAP RING,#125, Ext
|
IH
RING - external retaining, 1-5/32 inch Superseded by part number: 40974
|
| 40. |
109461
|
[1] |
LUBE NIPPLE,1/8"-27 x .66 lg
|
IH
NIPPLE, LUBE, , PTF 1/8"-27 x .66 lg Superseded by part number: 80710
|
| 41. |
ZA104464
|
[1] |
STOP
|
IH
- left Superseded by part number: 198025A1, 198026A1
|
| 42. |
407211R1
|
[2] |
CLIP
|
IH
PIN - clip
|
| 43. |
ZA104413
|
[1] |
LOCKING PLATE
|
IH
- lock
|
| 44. |
1281008C1
|
[1] |
SPRING
|
IH
- extension
|
| 45. |
ZA104754
|
[2] |
BRACKET
|
IH
- pickup mounting
|
| 46. |
131016
|
[2] |
WASHER
|
IH
- flat, 21/32 x 1-5/16 x 3/32 inch (16 x 33 x 2 mm) Superseded by part number: 396-21066, 396-21066, NLS
|
| 47. |
ZA104503
|
[1] |
STOP
|
IH
- right Superseded by part number: 198026A1, 198025A1
|
| 48. |
ZA762032
|
[1] |
SPRING
|
IH
|
| 49. |
ZA761517
|
[1] |
PLUG
|
IH
- spring
|
| 50. |
120378
|
[1] |
NUT,Hex, 1/2" - 13, Gr 5
|
IH
NUT, 1/2"-13, G5 Superseded by part number: 280431
|
| 51. |
480556C1
|
[1] |
BOLT,Spcl, 1/2" - 13 x 8"
|
IH
- hex, 1/2 NC x 8 inch
|
| 52. |
ZA104441
|
[1] |
SHAFT
|
IH
- pivot right
|
| 53. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
DECAL, GREASE (10 hours) (Order kit 1265869C93)
|
| 54. |
ZA103666
|
[20] |
DIVIDER
|
IH
TOOTH DIVIDER - long
|
| 55. |
ZA103667
|
[3] |
DIVIDER
|
IH
TOOTH DIVIDER - short
|
| 56. |
ZA103715
|
[8] |
ANGLE
|
IH
- tooth support
|
| 57. |
ZA104545
|
[1] |
BRACKET
|
IH
ASSEMBLY
|
