| 1. | D8NN4010JA | [1] | AXLE HOUSING | FORHousing Assy., Axle, R.H., D60, Includes: Ref 2 thru 5, Years: -30-NOV-91 Superseded by part number: 83934812 |
| 1. | 83958911 | [1] | HOUSING | AAssy., Axle, R.H., D60CHD1, Includes: Ref 2 thru 5 |
| 1. | E7NN4010AA | [1] | HOUSING | BASAssy., Axle, R.H., D60CHD2, Includes: Ref 2 thru 5 Superseded by part number: 83959621 |
| 1. | F0NN4010CA | [1] | SUMP | FORHousing Assy., Axle, R.H., D62, Includes: Ref 2 thru 5 |
| 1. | E9NN4010AA | [1] | ENVELOPE | BASHousing Assy., Axle, R.H., D60, Includes: Ref 2 thru 5, Start Year: 01-NOV-91 Superseded by part number: 83417087, 82982842, 81803416, 81803341, 80272684 |
| 1. | D8NN4011GA | [1] | AXLE HOUSING | FORHousing Assy., Axle, L.H., D60, Includes: Ref 2 thru 5 Superseded by part number: 83934813 |
| 1. | E6NN4011CB | [1] | HOUSING | BASAssy., Axle, L.H., D60CHD1, Includes: Ref 2 thru 5 |
| 1. | 83959622 | [1] | HOUSING | BASAssy., Axle, L.H., D60CHD2, Includes: Ref 2 thru 5 |
| 1. | F0NN4011BA | [1] | SUMP | FORHousing Assy., Axle, L.H., D62, Includes: Ref 2 thru 5 |
| 1. | E9NN4011AA | [1] | ENVELOPE | BASHousing Assy., Axle, L.H., D60, Includes: Ref 2 thru 5, Start Year: 01-NOV-91 Superseded by part number: 82989152, 83417087, 81803416, 81803341, 80272684 |
| 2. | 81803341 | [2] | RING GEAR | FORGear, Axle Planetary Ring, Standard |
| 2. | 81870541 | [2] | RING GEAR,80 T | BASGEAR, RING, Axle Planetary, D60, Start Year: 01-NOV-91 |
| 3. | 83417087 | [4] | STUD,1/2"-13-20 x 7 3/4" | BASStandard 1/2"-13-20 x 7 3/4" |
| 4. | 272684 | [2] | BEARING CUP | GIAxle Shaft, Inner, Standard Superseded by part number: 80272684 |
| 5. | 81834074 | [2] | CUP,117.47mm OD x 19.05mm W | FORAxle Shaft, Outer, D62 |
| 5. | 81803416 | [2] | BEARING CUP,112.74mm OD x 19.1mm W | BASCup, Axle Shaft, Outer, D60 |
| 5. | 86516474 | [2] | BEARING CUP | GICup, Axle Shaft, Outer, D60CHD1, D60CHD2 Superseded by part number: 81866516 |
| 6. | 81834054 | [2] | BEARING ASSY,77.79mm ID x 25.4mm W | BASCone & Roller Assy., Axle Shaft, Outer, D62 |
| 6. | 86516475 | [2] | ROLLER BEARING | WINCone & Roller Assy., Axle Shaft, Outer, D60CHD1, D60CHD2 Superseded by part number: 86627199 |
| 6. | 81803410 | [2] | BEARING ASSY,73.03mm ID x 25.53mm W | BASBEARING, ROLLER, TAPERED, Cone & Roller Assy, Axle Shaft, Outer, D60 |
| 7. | D9NN1187AA | [2] | SEAL | FORAxle Shaft, D62 Superseded by part number: 83925420 |
| 7. | 83958913 | [2] | SEAL,101.22mm ID x 135.2mm OD x 15.01mm Thk | BASAxle Shaft, D60CHD1, D60CHD2 |
| 7. | E5NN4N297AA | [2] | SEAL | BASAxle Shaft, D60 Superseded by part number: 83955527 |
| 7. | 81866390 | [2] | OIL SEAL,88.52mm ID x 123.29mm OD x 22.94mm Thk | BASSeal, Axle Shaft, Cassette Type, D60, 3.485" I.D.x4.854" O.D., Start Year: 01-NOV-91 |
| 8. | F2NN4969BA | [2] | RETAINER | FOROuter Seal, D60 Superseded by part number: 81878177 |
| 9. | E5NN4244BA | [2] | AXLE | BASDisc & Shaft Assy., Axle, D60, Includes: Ref. 10 Superseded by part number: 83955524 |
| 9. | E9NN4244AB | [2] | REAR AXLE | BASAXLE, REAR, Disc & Shaft Assy, D60, Includes: Ref. 10, Start Year: 01-NOV-91 Superseded by part number: 81867276 |
| 9. | 86568108 | [2] | SHAFT | FORDisc & Shaft Assy., Axle, 12 Holes, 275mm Bolt Circle (Does not include studs), D60CHD2 |
| 9. | 86564282 | [2] | SHAFT | BASDisc & Shaft Assy., Axle, 14 Holes, 12" Bolt Circle, D60CHD1,D60CHD2 |
| 9. | 83900162 | [2] | SHAFT | FORDisc & Shaft Assy., Axle, D62 |
| 10. | E3NN1N118AB | [24] | STUD | BASRight Rear, Axle Shaft to Right Rear Wheel Disc, D60CHD2 Superseded by part number: 83955491 |
| 10. | 83955490 | [16] | SCREW,3/4"-16 x 59mm | BASWHEEL BOLT, , Stud (2.32"), D60, D60HD 3/4"-16 x 59mm, Start Year: 01-NOV-91 Superseded by part number: 83955491 |
| 11. | D3NN1120B | [24] | WHEEL NUT | BASWheel, 3/4"-16UNF Superseded by part number: 81833776 |
| 12. | D4NN1107A | [28] | BOLT | FORTappered Shoulder, 3/4"-10UNC |
| 12. | 58741S36 | [28] | BOLT,Hex, 3/4"-10 x 2", G8 | FORHH, G8, 3/4"-10 x 2" Superseded by part number: F0NN3A343AA, 9635076 |
| 13. | 86505999 | [18] | BOLT,Hex, 5/8" - 11 x 2", Gr 5 | NHCap, HH, G5, 5/8"-11 x 2", D60CHD1 |
| 13. | 16445 | [4] | BOLT,Hex, 5/8" - 11 x 3 3/4", Gr 5 | BASScrew, Cap, HH, G5, 5/8"-11 x 3-3/4", D60CHD2,D62 |
| 13. | 87338 | [2] | BOLT,Hex, 5/8" - 11 x 3", Gr 5 | NHD60CHD1 Hex, 5/8"-11 x 3", G5 |
| 14. | E9NN4N317AA | [2] | O-RING,3.63mm Thk x 328.14mm ID | BAS13" ID x .140" Thk (Seal), Brake & Trumpet Housing, D60, Start Year: 01-NOV-91 Superseded by part number: 83997832 |
| 14. | 83417133 | [2] | O-RING,3.63mm Thk x 336.91mm ID | FOR13.50" ID x .139" Thk (Seal), Standard |
| 15. | D9NN4N029AA | [2] | PLANETARY GEAR | BASCarrier Assy., Axle Planetary, 3 Gear, Standard Superseded by part number: 83926965 |
| 15. | D0NN4N029A | [2] | PINION CARRIER | BASCarrier Assy., Axle Planetary, 3 Gear, D60, Start Year: 01-NOV-91 Superseded by part number: 81802412, 81802412, C5NN4A007A, 81802412, C5NN4A007A, C5NN4A008A, 81802412, C5NN4A007A, C5NN4A008A, D0NN4044A, 81802412, C5NN4A007A, C5NN4A008A, D0NN4044A, D0NN4048A, 81802412, C5NN4A007A, C5NN4A008A, D0NN4044A, D0NN4048A, D0NN4N030A, 81802412, C5NN4A007A, C5NN4A008A, D0NN4044A, D0NN4048A, D0NN4N030A, DAPN4013A |
| 15. | E1NN4N029AA | [2] | SUPPORT | BASCarrier Assy., Axle Planetary, 4 Gear Includes: 16 thru 22 Superseded by part number: 83930904 |
| 16. | 81802412 | [2] | ROLLER BEARING,95.25mm ID x 36.32mm W | FORBEARING, ROLLER, Cone & Roller Assy, Standard |
| 17. | D0NN4048A | [6] | SHAFT | BASAxle Planetary, 3 Gear, Standard Superseded by part number: 81823521 |
| 18. | DAPN4013A | [1] | KIT | BASNeedle Repair, (1) Kit per Gear Superseded by part number: 81823554 |
| 19. | 81803272 | [1] | THRUST WASHER,45.92mm ID x 67.69mm OD x 0.81mm Thk | FORAxle Planetary Gear, (2) per Gear, 3 Gear 1.818" x 2.665" x .030" Thk, HT |
| 20. | C5NN4A008A | [6] | SPACER | FORPlanetary Gear Needle Bearing, 3 Gear Superseded by part number: 81803274 |
| 21. | 81823520 | [6] | GEAR,20 Teeth | BASAxle Planetary, 3 Gear, Standard 20 Teeth |
| 22. | 81820847 | [2] | RING,2.08mm Thk, Ext | FORAxle Planetary, 3 Gear, Standard 4.52" ID |
| 22. | E1NN4N031AA | [2] | RETAINER | BASAxle Planetary, 4 Gear Superseded by part number: 83930905 |
| 23. | 81803491 | [1] | SHIM,22.86mm ID x 53.85mm OD x 1.27mm Thk | BASBearing, Right Rear Axle Shaft .90" x 2.12" x .049/.050" Thk |
| 23. | 81803502 | [1] | SHIM,22.86mm ID x 53.85mm OD x 1.37mm Thk | BASBearing, Right Rear Axle Shaft .90" x 2.12" x .053/.054" Thk |
| 23. | 81803503 | [1] | SHIM,22.86mm ID x 53.85mm OD x 1.47mm Thk | BASBearing, Right Rear Axle Shaft .90" x 2.12" x .057/.058" Thk |
| 23. | 81803504 | [1] | SHIM,22.86mm ID x 53.85mm OD x 1.58mm Thk | BASBearing, Right Rear Axle Shaft .90" x 2.12" x .061/.062" Thk |
| 23. | 81803505 | [1] | SHIM,22.86mm ID x 53.85mm OD x 1.68mm Thk | BASBearing, Right Rear Axle Shaft .90" x 2.12" x .065/.066" Thk |
| 23. | 81803506 | [1] | SHIM,22.86mm ID x 53.85mm OD x 1.78mm Thk | BASBearing, Right Rear Axle Shaft .90" x 2.12" x .069/.070" Thk |
| 23. | 81803507 | [1] | SHIM,22.86mm ID x 53.85mm OD x 1.88mm Thk | FORBearing, Right Rear Axle Shaft .90" x 2.12" x .073/.074" Thk |
| 23. | 81803508 | [1] | SHIM,22.86mm ID x 53.85mm OD x 1.98mm Thk | BASBearing, Right Rear Axle Shaft .90" x 2.12" x .077/.078" Thk |
| 23. | 81803509 | [1] | SHIM,22.86mm ID x 53.85mm OD x 2.08mm Thk | BASBearing, Right Rear Axle Shaft .90" x 2.12" x .081/.082" Thk |
| 23. | 81803510 | [1] | SHIM,22.86mm ID x 53.85mm OD x 2.18mm Thk | BASBearing, Right Rear Axle Shaft .90" x 2.12" x .085/.086" Thk |
| 23. | 81803511 | [1] | SHIM,22.86mm ID x 53.85mm OD x 2.29mm Thk | BASBearing, Right Rear Axle Shaft .90" x 2.12" x .089/.090" Thk |
| 24. | D0NN4N237A | [2] | WASHER | BASRetainer, Axle Shaft Superseded by part number: 81823556 |
| 25. | D0NN4N240A | [2] | LOCKING PLATE | BASLock, Bolt, Axle Shaft Superseded by part number: 81823525 |
| 26. | 304842S36 | [2] | BOLT,Hex, 7/8"-9 x 2", G5 | FOR Superseded by part number: 413-1432 |
| 27. | 81823522 | [2] | PLANETARY GEAR | BASGear, Axle Sun, Standard |
| 31. | 81803516 | [1] | SHIM,96.52mm ID x 111.76mm OD x 1.17mm Thk | BAS(1.118/1.168 mm), Bearing, Axle Shaft Differential 3.80" x 4.40" x .044/.046" Thk |
| 31. | 81803517 | [1] | SHIM,96.52mm ID x 111.76mm OD x 1.32mm Thk | BAS(1.270/1.321 mm), Bearing, Axle Shaft Differential 3.80" x 4.40" x .050/.052" Thk |
| 31. | 81803518 | [1] | SHIM,96.52mm ID x 111.76mm OD x 1.47mm Thk | BAS3.80" x 4.40" x .056/.058" Thk (1.422/1.473 mm), Bearing, Axle Shaft Differential |
| 31. | 81803519 | [1] | SHIM,96.52mm ID x 111.76mm OD x 1.63mm Thk | BAS(1.575/1.626 mm), Bearing, Axle Shaft Differential 3.80" x 4.40" x .062/.064" Thk |
| 31. | 81803520 | [1] | SHIM,96.52mm ID x 111.76mm OD x 1.78mm Thk | BAS(1.727/1.778 mm), Bearing, Axle Shaft Differential 3.80" x 4.40" x .068/.070" Thk |
| 31. | 81803521 | [1] | SHIM,96.52mm ID x 111.76mm OD x 1.93mm Thk | BAS(1.880/1.930 mm), Bearing, Axle Shaft Differential 3.80" x 4.40" x .074/.076" Thk |
| 31. | 81803522 | [1] | SHIM,96.52mm ID x 111.76mm OD x 2.08mm Thk | BAS(2.032/2.083 mm), Bearing, Axle Shaft Differential 3.80" x 4.40" x .080/.082" Thk |
| 32. | 510892 | [1] | BEARING CUP,112.71mm OD x 23.81mm W | GICup, Bearing, Axle Differential |
| 33. | 510884 | [1] | ROLLER BEARING,66.69mm ID x 30.05mm W | WINCone Assy., Bearing, Axle Differential |
| 34. | 280963 | [4] | NUT,Nut, 1/2-20 GR 5 ZND | NHG5, 1/2"-20 |
| 35. | C5NN4194B | [1] | BLOCK | FORThrust, Rear Axle Driven Gear, 5.286:1 Ratio Superseded by part number: 81803367 |
| 35. | 83959624 | [1] | BLOCK | BASThrust, Rear Axle Driven Gear, 4.622:1 Ratio |
| 35. | C5NN4194G | [1] | BLOCK | FORThrust, Rear Axle Driven Gear, 3.500:1 Ratio Superseded by part number: 81825447 |
| 36. | 80680 | [2] | LOCK WASHER,3/8 0.381 CST ZND | NHWASHER, LOCK, 3/8" |
| 37. | 88206 | [2] | BOLT,Hex, 3/8" - 16 x 1", Gr 5 | NH |
| 38. | F0NN4N319AA | [2] | PLUG | BASPull Rod Opening, L/Brake Models, Not Shown Superseded by part number: 83991145 |
