| 34. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
CHAIN ASSEMBLY (Use 33 links from roll marked 569089R91 1 offset link 456929R91 and connecting link 587372R91) (For power reduction use 31 links)
|
| . . |
569089R91
|
[1] |
CHAIN (AG),10' L, 1.0" Pitch
|
IH
CHAIN - 10 foot (3.048 m) roll
|
| . . |
456929R91
|
[1] |
CHAIN LINK
|
IH
LINK - offset Superseded by part number: 86595273
|
| . . |
587372R91
|
[1] |
CONNECTING LINK
|
IH
LINK - connecting Superseded by part number: 242-1310
|
| 35. |
1281010C1
|
[2] |
BUSHING
|
IH
|
| 36. |
668902R1
|
[1] |
BELT
|
IH
- Speed up (Used with sheave ZA104645) (Interchangeable with ZA104774)
|
| 36. |
ZA104774
|
[1] |
BELT
|
IH
- Slow down (Use with sheave ZA104842) (Interchangeable with 668902R1)
|
| 37. |
ZA104375
|
[1] |
PULLEY
|
IH
SHEAVE AND SPROCKET ASSEMBLY
|
| 38. |
ZA104443
|
[1] |
SHAFT
|
IH
- pivot left
|
| 39. |
152450R1
|
[1] |
SNAP RING,#125, Ext
|
IH
RING - external retaining, 1/5-32 inch Superseded by part number: 40974
|
| 40. |
109461
|
[1] |
LUBE NIPPLE,1/8"-27 x .66 lg
|
IH
NIPPLE, LUBE, , PTF 1/8"-27 x .66 lg Superseded by part number: 80710
|
| 41. |
ZA104464
|
[1] |
STOP
|
IH
- left Superseded by part number: 198025A1, 198026A1
|
| 42. |
407211R1
|
[2] |
CLIP
|
IH
PIN - clip
|
| 43. |
ZA104413
|
[1] |
LOCKING PLATE
|
IH
- lock
|
| 44. |
ZA290043
|
[1] |
SPRING
|
IH
- extension
|
| 45. |
ZA104754
|
[2] |
BRACKET
|
IH
|
| 46. |
ZA100457
|
[1] |
ANGLE
|
IH
CLIP - angle
|
| 47. |
ZA104503
|
[1] |
STOP
|
IH
- right Superseded by part number: 198026A1, 198025A1
|
| 48. |
ZA762032
|
[1] |
SPRING
|
IH
|
| 49. |
ZA761517
|
[1] |
PLUG
|
IH
- spring
|
| 50. |
9635884
|
[84] |
BOLT,Hex, 5/16" - 18 1", Full Thd, Gr 5
|
NH
- hex, 5/16 NC x 3/4 inch
|
| 51. |
480556C1
|
[1] |
BOLT,Spcl, 1/2" - 13 x 8"
|
IH
- hex, 1/2 NC x 8 inch
|
| 52. |
ZA104441
|
[1] |
SHAFT
|
IH
- pivot right
|
| 53. |
NLS
|
[2] |
NO LONGER SERVICED
|
BAS
- flat, 21/32 x 1-5/16 x 3/32 inch (16 x 33 x 2 mm)
|
| 55. |
9413979
|
[45] |
LOCK NUT,3/8"-16, GC
|
IH
NUT - hex lock, 3/8 inch NC Superseded by part number: 232-4136
|
| 56. |
9413956
|
[4] |
LOCK NUT,1/2"-13, GB
|
IH
NUT - hex lock, 1/2 inch NC Superseded by part number: 231-4138
|
| 57. |
ZA104203
|
[1] |
REEL
|
IH
- pickup
|
| 58. |
ZA104224
|
[1] |
SHAFT
|
IH
- right
|
| 60. |
180183
|
[1] |
BOLT,Hex, 1/2" - 13 x 2 1/4", Gr 5
|
IH
- hex, 1/2 NC x 2-1/4 inch Superseded by part number: 113-441
|
| 61. |
120378
|
[1] |
NUT,Hex, 1/2" - 13, Gr 5
|
IH
NUT, 1/2"-13, G5 Superseded by part number: 280431
|
| 62. |
120394
|
[16] |
WASHER,3/8", SAE
|
IH
WASHER - flat, 13/32 x 13/16 x 1/16 inch (10 x 20 x 1 mm) Superseded by part number: 87016
|
