| 1. | E4NN2N099AA | [1] | HOUSING | FORR.H. Inner Brake (used on left side of axle) Superseded by part number: D9NN2N099BA, 83955514 |
| 1. | E4NN2N100CA | [1] | HOUSING | FORL.H. Inner Brake (used on right side of axle) Superseded by part number: 83955515, D9NN2N100AA |
| 2. | 86539262 | [2] | NUT,1/2"-20, Gr 8 | NH |
| 3. | 81802547 | [2] | PIN | FOR |
| 4. | 83959626 | [4] | DISC,53.34mm ID x 224mm OD x 4.9mm Thk | BASSM17WP |
| 5. | 83956598 | [2] | DISC,145.8mm ID x 230.1mm OD x 2.7mm Thk | BASIntermediate |
| 6. | 83956597 | [1] | ACTUATOR | BASDisc Assy, 18° (Includes 7-11) |
| 7. | 81818828 | [2] | BOLT | FORPIN, PIVOT |
| 8. | 81818856 | [2] | LINK | FORPlain |
| 9. | 80087309 | [2] | NUT | IMOJam, 1/2-20 Superseded by part number: 87309 |
| 10. | 82979987 | [6] | BALL,7/8" | CUR |
| 11. | 84814903 | [4] | SPRING | FOR |
| 12. | 83964342 | [1] | HOUSING | BASOuter Brake |
| 13. | 81823522 | [1] | PLANETARY GEAR | BASGear, Planetary Sun |
| 14. | 83959621 | [1] | SHAFT HOUSING | FORR.H., Includes Ref. 15,16 & 18 |
| 14. | 83959622 | [1] | HOUSING | BASL.H., Includes Ref. 15,16 & 18 |
| 15. | 81803341 | [1] | RING GEAR | FORGear, Planetary Ring |
| 16. | 86516474 | [1] | BEARING CUP | GICup, Roller Bearing, Outer Superseded by part number: 81866516 |
| 17. | 377525S | [2] | STUD | FOR Superseded by part number: 83417087 |
| 18. | 272684 | [1] | BEARING CUP | GIBearing, Inner Superseded by part number: 80272684 |
| 19. | 304842S36 | [1] | BOLT,Hex, 7/8"-9 x 2", G5 | FOR Superseded by part number: 413-1432 |
| 20. | D9NN4N029AA | [1] | PLANETARY GEAR | BASCarrier Assy., Incl. Ref.21-27 Superseded by part number: 83926965 |
| 21. | 81802412 | [1] | ROLLER BEARING,95.25mm ID x 36.32mm W | FORBEARING, ROLLER, Cone, Inner |
| 22. | D0NN4048A | [3] | SHAFT | BASPlanet Gear Superseded by part number: 81823521 |
| 23. | DAPN4013A | [3] | KIT | BASNeedle Bearing, 58 Bearings=1 Kit Superseded by part number: 81823554 |
| 24. | 81803272 | [6] | THRUST WASHER,45.92mm ID x 67.69mm OD x 0.81mm Thk | FOR |
| 25. | C5NN4A008A | [3] | SPACER | FOR Superseded by part number: 81803274 |
| 26. | 81823520 | [3] | GEAR,20 Teeth | BASPlanetary, 20 Teeth |
| 27. | 81820847 | [1] | RING,2.08mm Thk, Ext | FOR |
| 28. | D0NN4N237A | [1] | WASHER | BASRetainer Superseded by part number: 81823556 |
| 29. | 81803491 | [1] | SHIM,22.86mm ID x 53.85mm OD x 1.27mm Thk | BAS(1.245/1.321mm) .90" x 2.12" x .049/.050" Thk |
| 29. | 81803502 | [1] | SHIM,22.86mm ID x 53.85mm OD x 1.37mm Thk | BAS |
| 29. | 81803503 | [1] | SHIM,22.86mm ID x 53.85mm OD x 1.47mm Thk | BAS |
| 29. | 81803504 | [1] | SHIM,22.86mm ID x 53.85mm OD x 1.58mm Thk | BAS(1.549/1.575mm) .90" x 2.12" x .061/.062" Thk |
| 29. | 81803505 | [1] | SHIM,22.86mm ID x 53.85mm OD x 1.68mm Thk | BAS |
| 29. | 81803506 | [1] | SHIM,22.86mm ID x 53.85mm OD x 1.78mm Thk | BAS |
| 29. | 81803507 | [1] | SHIM,22.86mm ID x 53.85mm OD x 1.88mm Thk | FOR(1.854/1.880 mm) .90" x 2.12" x .073/.074" Thk |
| 29. | 81803508 | [1] | SHIM,22.86mm ID x 53.85mm OD x 1.98mm Thk | BAS(1.956/1.981 mm) .90" x 2.12" x .077/.078" Thk |
| 29. | 81803509 | [1] | SHIM,22.86mm ID x 53.85mm OD x 2.08mm Thk | BAS(2.057/2.083 mm) .90" x 2.12" x .081/.082" Thk |
| 29. | 81803510 | [1] | SHIM,22.86mm ID x 53.85mm OD x 2.18mm Thk | BAS(2.159/2.184 mm) .90" x 2.12" x .085/.086" Thk |
| 29. | 81803511 | [1] | SHIM,22.86mm ID x 53.85mm OD x 2.29mm Thk | BAS |
| 30. | D0NN4N240A | [1] | LOCKING PLATE | BASBolt, Lock Superseded by part number: 81823525 |
| 35. | 82037652 | [1] | SEAL | FARAssy., Boot |
| 36. | 81877008 | [1] | ROD | BASBrake Control, 7.03" x 12mm x1.75mm |
| 39. | PL | [1] | PROCURE LOCALLY | BASPin, Cotter, 1/8"x1" |
| 40. | 76260S36 | [1] | CLEVIS PIN,5/8" x 1 3/8" L | BASPIN, CLEVIS, 5/8" x 1 3/8" L Superseded by part number: 83928668 |
| 41. | 87753 | [11] | BOLT,Hex, 3/8" - 24 x 2", Gr 5 | WIN5/8"-11 x 2" |
| 42. | 86568108 | [1] | SHAFT | FOR |
| 43. | E3NN1N118AB | [12] | STUD | BAS3/4"-16 x 2-5/8" Superseded by part number: 83955491 |
| 44. | 83958913 | [1] | SEAL,101.22mm ID x 135.2mm OD x 15.01mm Thk | BAS |
| 45. | 86516475 | [1] | ROLLER BEARING | WINCone, Roller Bearing, Outer Superseded by part number: 86627199 |
| 46. | 83417133 | [1] | O-RING,3.63mm Thk x 336.91mm ID | FOR13.50" ID x .139" Thk (Seal) |
| 47. | 88574 | [6] | BOLT,Hex, 5/16" - 18 x 1/2", Gr 5, Full Thd | NH |
| 48. | 83959624 | [1] | BLOCK | BASThrust (3.500, 4.111, 4.625 Ratios) |
| 48. | C5NN4194B | [1] | BLOCK | FORThrust (5.286, 6.667 Ratios) Superseded by part number: 81803367 |
| 49. | 80680 | [2] | LOCK WASHER,3/8 0.381 CST ZND | NHWASHER, LOCK, 3/8" |
| 50. | 88206 | [2] | BOLT,Hex, 3/8" - 16 x 1", Gr 5 | NH |
