神钢零件查询(4JB1) - ISUZU DIESEL ENGINE (1/06-12/07) (01-011[02]) - OIL PIPE & FIXING PARTS Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
399 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VI8941421573 | [1] | PUMP ASM,OIL,W/STRAINER | |
| 1. | VI8941701224 | [1] | PUMP ASM. ,OIL,W/STRAINER | |
| 1-1. | VI5131000613 | [1] | PUMP ASM,OIL,W/STRAINER | |
| 1. | VI8944287983 | [1] | PUMP ASM,OIL.H/STRAINER | |
| 1-4. | VI8970652321 | [1] | PUMP ASM,OIL.W/STRAINER | |
| 1. | VI8943629233 | [1] | ENGINE OIL PUMP | KOBPUMP ASM,OIL,H/STRAINER |
| 1-2. | VI8944432273 | [1] | ENGINE OIL PUMP | KOBPUMP ASM,OIL,W/STRAINER |
| 3. | VI8970441120 | [1] | REPAIR KIT | KOBREPAIR KIT,OIL PUMP |
| 3. | NSS | [1] | NOT SOLD SEPARAT | CONREPAIR KIT,OIL PUMP |
| 7. | VI8941761790 | [1] | STRAINER ASM. | |
| 7-1. | VI5131410140 | [1] | CASE,STRAINER | |
| 7. | VI9131401200 | [1] | STRAINER ASM. | |
| 7. | VI8970298000 | [1] | STRAINER ASM. | |
| 7. | VI8970443490 | [1] | STRAINER ASM. | |
| 7. | VI5131400090 | [1] | STRAINER ASM. | |
| 7. | NSS | [1] | NOT SOLD SEPARAT | CONSTRAINER ASM. |
| 8. | NSS | [1] | NOT SOLD SEPARAT | CONPINION |
| 9. | VI9019008250 | [4] | BOLT | KOBBOLT,COVER FIX.,L=25 |
| 9-1. | VI9019008250 | [2] | BOLT | KOBBOLT,COVER FIX.,L=25 |
| 9-2. | VI5090300310 | [2] | BOLT,COVER FIX.,L=50 | |
| 9-3. | VI9019008120 | [1] | BOLT,COVER FIX.,L=12 | |
| 10. | VI8941761780 | [1] | PIPE ASM. | |
| 10. | VI8943380790 | [1] | PIPE ASM. | |
| 10. | VI8970298010 | [1] | PIPE ASM. | |
| 10. | NSS | [1] | NOT SOLD SEPARAT | CONPIPE ASM. |
| 10. | VI8944464080 | [1] | CASE ASM. | |
| 11. | VI8944464110 | [1] | GAUZE | |
| 11. | VI9131430100 | [1] | FILTER STRAINER | KOBGAUZE |
| 11. | VI9131436031 | [1] | GAUZE | |
| 12. | VI9131130860 | [1] | COVER,OIL PUMP | |
| 12. | VI9131130771 | [1] | COVER | KOBCOVER,OIL PUMP |
| 12. | VI8944435941 | [1] | COVERIOIL PUMP | |
| 14. | VI9081040300 | [1] | PIN | KOBPIN,SPLIT,OIL PUMP |
| 15. | VI5131650040 | [1] | SPRING SEAT | KOBSEAT,SPRING,OIL PUMP |
| 16. | VI8970368340 | [1] | SPRING,OIL PUMP | |
| 17. | VI8942355671 | [1] | VALVE | KOBVALVE,OIL PUMP |
| 20. | VI0501408250 | [2] | BOLT | KOBBOLT,OIL PUMP-CYL.BLOCK Superseded by part number: VI0506408250 |
