神钢零件查询(4JB1) - ISUZU DIESEL ENGINE (1/06-12/07) (01-014) - CRANKSHAFT, CRANK METAL, PISTON, CONN. ROD & FLYWHEEL Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
366 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VI8941685520 | [1] | KIT | KOBMETAL KIT,CRANK,(NO UNSI) |
| 2. | VI8944537620 | [1] | WASHER | KOBMETAL KIT,THRUST |
| 3. | VI8971345280 | [4] | PISTON | KOBPISTON |
| 3. | VI8944331771 | [4] | PISTON | KOB Superseded by part number: VI8971766040 |
| 3. | VI8943406202 | [4] | PISTON | |
| 5. | VI8942478671 | [4] | RING | KOBRING SET,PISTON Superseded by part number: 8942478671 |
| 5. | VI8970298640 | [4] | ring set,piston | |
| 6. | VI8943296921 | [4] | CONNECTING ROD | KOBROD ASM.,CONN. Superseded by part number: VI8943296922 |
| 6-1. | VI8970623000 | [4] | ROD ASM.,CONN. | |
| 7. | VI8944197291 | [8] | BOLT BOLT,CONN.ROD | BOLT BOLT,CONN.ROD |
| 7. | VI5122350090 | [8] | SCREW | KOBBOLT,CONN.ROD(94-9-) |
| 7. | VI8970620860 | [8] | BOLT | KOBBOLT,CONN.ROD |
| 8. | VI5094090160 | [8] | NUT NUT,CONN.ROD | NUT NUT,CONN.ROD |
| 9. | VI9081605080 | [4] | PIN | KOBPIN,CONN.ROD Superseded by part number: 86990184 |
| 10. | VI8944194550 | [4] | BUSHING | KOBBUSH,CONN.ROD Superseded by part number: VI8973528890 |
| 10. | VI8944571580 | [4] | BUSH,CONN.ROD | |
| 11. | VI8943241590 | [4] | CONNECTION | KOBMETAL SET, CONN.ROD Superseded by part number: 87594036 |
| 12. | VI8944544790 | [4] | PIN | KOBPIN-.PISTON, ID=16 |
| 12. | VI8944570080 | [4] | PIN,PISTON | |
| 13. | VI8941339690 | [8] | SNAP RING | KOBSNAP RING |
| 13. | VI8944606870 | [8] | RING | KOBSNAP RING |
| 15. | VI8944436620 | [1] | CRANKSHAFT | KOBCRANKSHAFT,D=70 TUFFT |
| 15. | VI8944535252 | [1] | CRANKSHAFT,D=70 TUFFT | |
| 16. | VI8970407560 | [1] | FLYWHEEL ASM | |
| 16. | VI8944767320 | [1] | FLYWHEEL ASM | |
| 16-2. | VI8970644650 | [1] | FLYWHEEL ASM. | |
| 16-4. | VI8944104072 | [1] | FLYWHEEL ASM. | |
| 16-5. | VI8944314702 | [1] | FLYWHEEL ASM. | |
| 16-1. | VI8970478740 | [1] | FLYWHEEL ASM. | |
| 17. | VI8944196020 | [1] | SHAFT | KOBGEAR,RING Superseded by part number: 353953A1 |
| 17. | VI8941712900 | [1] | GEAR,RING | |
| 18. | VI8970659841 | [8] | BOLT | KOBBOLT,FLYWHEEL FIX. |
| 18. | VI8944274560 | [8] | BOLT,FLYWHEEL FIX. | |
| 19. | VI8941421561 | [1] | WASHER | KOBWASHER,FLYWHEEL |
| 20. | VI9000906790 | [1] | BEARING,BALL | |
| 21. | VI8944488891 | [1] | KEY,FEATHER | |
| 21. | VI9080307430 | [1] | KEY,FEATHER | |
| 22. | VI8943243350 | [1] | GEAR | KOBGEAR,CRANKSHAFT |
| 22. | VI5125210250 | [1] | DRIVING GEAR | KOBGEAR,CRANKSHAFT |
| 22. | VI8941397540 | [1] | GEAR,CRANKSHAFT | |
| 22. | VI8941723650 | [1] | GEAR,CRANKSHAFT | |
| 22. | VI8943284470 | [1] | GEAR,CRANKSHAFT | |
| 23-1. | VI8944297460 | [1] | PULLEY | KOBPULLEY,CRANKSHAFT |
| 23-1. | VI8943208220 | [1] | PULLEY,CRANKSHAFT | |
| 23-1. | VI8944535510 | [1] | PULLEY,CRANKSHAFT | |
| 23. | VI8944535521 | [1] | PULLEY,CRANKSHAFT(95-6-) | |
| 23. | VI8944535522 | [1] | PULLEY,CRANKSHAFT(96-7-) | |
| 23. | VI8944294230 | [1] | PULLEY ASM,DAMPER | |
| 23-1. | VI8943761862 | [1] | PULLEY,CRANKSHAFT,TAPER | |
| 23-1. | VI8943813042 | [1] | PULLEY,CRANKSHAFT.D=145 | |
| 23-2. | VI8970718660 | [1] | PULLEY,CRANKSHAFT | |
| 23-2. | VI8971680730 | [1] | PULLEY,CRANKSHAFT.W/DAMPE(96-11-) | |
| 24. | VI8941537221 | [1] | BOLT,PULLEY FIX | |
| 24. | VI8944334060 | [1] | SCREW | KOBBOLT,CRANK PULLEY |
| 24. | VI5090002732 | [1] | BOLT | KOBBOLT,CRANK PULLEY(96-4-) |
| 24. | VI8943140680 | [1] | BOLT,CRANK PULLEY | |
| 25. | VI5095031270 | [1] | WASHER | KOBWASHER,CRANK PULLEY |
| 26. | VI8941739510 | [1] | SPACER,BRG..STOPPER | |
| 27. | VI8943193310 | [1] | BUSH,CARANKSHAFT | |
| 30. | VI5123310500 | [1] | FLYWHEEL,REAR | |
| 30. | VI8941754090 | [1] | FLYWHEEL,REAR | |
| 31. | VI9020610320 | [4] | BOLT,FLYWHEEL | |
| 32. | VI9098518660 | [4] | WASHER,BOLT | |
| 33. | VI9081506250 | [2] | PIN,STRAIGHT,CLUTCH | |
| 33. | VI9081508250 | [3] | PIN,STRAIGHT,CLUTCH | |
