| 0. | 82014378 | [1] | REPAIR KIT | BASKit, Add 5 Plate Brakes, Includes: Ref 1, 4, 5 & 6 |
| 1. | 83955514 | [1] | HOUSING | FORInner Brake Housing, RH, 4 Plate Brakes |
| 1. | E8NN2N099AA | [1] | HOUSING | FORInner Brake Housing, RH, 5 Plate Brakes Superseded by part number: 83977190 |
| 1. | E4NN2N100CA | [1] | HOUSING | FORInner Brake Housing, LH, 4 Plate Brakes Superseded by part number: 83955515, D9NN2N100AA |
| 1. | E8NN2N100AA | [1] | HOUSING | FORInner Brake Housing, LH, 5 Plate Brakes Superseded by part number: 83977191 |
| 2. | 86539262 | [2] | NUT,1/2"-20, Gr 8 | NH |
| 3. | 81802547 | [2] | PIN | FOR |
| 4. | 83959626 | [4/5] | DISC,53.34mm ID x 224mm OD x 4.9mm Thk | BASAssy., SM17WP |
| 5. | 83956598 | [2] | DISC,145.8mm ID x 230.1mm OD x 2.7mm Thk | BASAssy., Intermediate, 4 Plate Brakes |
| 5. | 82014455 | [3] | DISC | BASAssy., Intermediate, 5 Plate Brakes |
| 6. | 83956597 | [1] | ACTUATOR | BASDisc Assy, 4 Plate Brakes (Includes Ref 7 thru 11) |
| 6. | E8NN2N317BA | [1] | BRAKE ASSY. | FORDisc Assy., Actuating, 5 Plate Brakes, (Includes: Ref 7 thru 11) Superseded by part number: 83977189 |
| 7. | 81818828 | [2] | BOLT | FORPIN, PIVOT |
| 8. | 81818856 | [2] | LINK | FORPlain |
| 9. | 80087309 | [2] | NUT | IMOJam, 1/2-20 Superseded by part number: 87309 |
| 10. | 82979987 | [6] | BALL,7/8" | CUR |
| 11. | 84814903 | [4] | SPRING | FOR |
| 12. | 83964342 | [1] | HOUSING | BASOuter Brake Housing, 4/5 Plate Brakes |
| 13. | 81823522 | [1] | PLANETARY GEAR | BASGear, Planetary Sun |
| 14. | 82019781 | [1] | HOUSING | BASAssy., RH, D65, Includes ref. 15, 16 & 18 |
| 14. | 82019780 | [1] | HOUSING | BASAssy., LH, D65, Includes ref. 15, 16 & 18 Superseded by part number: 47771396 |
| 14. | 82017333 | [1] | HOUSING | BASAssy., RH, D65 Industrial, Includes ref. 15, 16 & 18, Years: -31-DEC-05 Superseded by part number: 81803341, 80272684, 160301R1, 87307081 |
| 14. | 87307080 | [1] | AXLE HOUSING | BASHousing Assy., RH, D65 Industrial, Includes: Ref 15, 16 & 18, Start Year: 01-JAN-06 Superseded by part number: 81803341, 87307081, 80272684, 160301R1 |
| 14. | 82017332 | [1] | HOUSING | BASAssy., LH, D65 Industrial, Includes ref. 15, 16 & 18, Years: -31-DEC-05 Superseded by part number: 87307083, 81803341, 160301R1, 80272684 |
| 14. | 87307082 | [1] | AXLE HOUSING | BASHousing Assy., LH, D65 Industrial, Includes: Ref 15, 16 & 18, Start Year: 01-JAN-06 Superseded by part number: 87307083, 160301R1, 80272684, 81803341 |
| 15. | 81803341 | [1] | RING GEAR | FORGear, Planetary Ring |
| 16. | 86516474 | [1] | BEARING CUP | GICup, Roller Bearing Outer Superseded by part number: 81866516 |
| 16. | 87307079 | [1] | BEARING ASSY,82.55 mm ID x 133.375 mm OD x 39.89 mm | BASCup, Roller Bearing, Outer, D65 Industrial, Start Year: 01-JAN-06 Superseded by part number: 160301R1 |
| 17. | 83417087 | [2] | STUD,1/2"-13-20 x 7 3/4" | BAS |
| 18. | 272684 | [1] | BEARING CUP | GIBearing, Inner Superseded by part number: 80272684 |
| 19. | 304842S36 | [1] | BOLT,Hex, 7/8"-9 x 2", G5 | FOR Superseded by part number: 413-1432 |
| 20. | D9NN4N029AA | [1] | PLANETARY GEAR | BASCarrier Assy., Includes 21 thru 27 Superseded by part number: 83926965 |
| 21. | 81802412 | [1] | ROLLER BEARING,95.25mm ID x 36.32mm W | FORBEARING, ROLLER, Cone, Inner |
| 22. | D0NN4048A | [3] | SHAFT | BASPlanet Gear Superseded by part number: 81823521 |
| 23. | DAPN4013A | [3] | KIT | BASNeedle Bearing (58 bearings/kit) Superseded by part number: 81823554 |
| 24. | 81803272 | [6] | THRUST WASHER,45.92mm ID x 67.69mm OD x 0.81mm Thk | FOR |
| 25. | C5NN4A008A | [3] | SPACER | FOR Superseded by part number: 81803274 |
| 26. | 81823520 | [3] | GEAR,20 Teeth | BASPlanetary, 20 Teeth |
| 27. | 81820847 | [1] | RING,2.08mm Thk, Ext | FOR |
| 28. | D0NN4N237A | [1] | WASHER | BASRetaining Superseded by part number: 81823556 |
| 29. | 81803491 | [1] | SHIM,22.86mm ID x 53.85mm OD x 1.27mm Thk | BAS(1.245/1.321mm) .90" x 2.12" x .049/.050" Thk |
| 29. | 81803502 | [1] | SHIM,22.86mm ID x 53.85mm OD x 1.37mm Thk | BAS |
| 29. | 81803503 | [1] | SHIM,22.86mm ID x 53.85mm OD x 1.47mm Thk | BAS |
| 29. | 81803504 | [1] | SHIM,22.86mm ID x 53.85mm OD x 1.58mm Thk | BAS(1.549/1.575mm) .90" x 2.12" x .061/.062" Thk |
| 29. | 81803505 | [1] | SHIM,22.86mm ID x 53.85mm OD x 1.68mm Thk | BAS(1.651/1.676mm) .90" x 2.12" x .065/.066" Thk |
| 29. | 81803506 | [1] | SHIM,22.86mm ID x 53.85mm OD x 1.78mm Thk | BAS |
| 29. | 81803507 | [1] | SHIM,22.86mm ID x 53.85mm OD x 1.88mm Thk | FOR |
| 29. | 81803508 | [1] | SHIM,22.86mm ID x 53.85mm OD x 1.98mm Thk | BAS |
| 29. | 81803509 | [1] | SHIM,22.86mm ID x 53.85mm OD x 2.08mm Thk | BAS(2.057/2.083 mm) .90" x 2.12" x .081/.082" Thk |
| 29. | 81803510 | [1] | SHIM,22.86mm ID x 53.85mm OD x 2.18mm Thk | BAS(2.159/2.184 mm) .90" x 2.12" x .085/.086" Thk |
| 29. | 81803511 | [1] | SHIM,22.86mm ID x 53.85mm OD x 2.29mm Thk | BAS |
| 30. | D0NN4N240A | [1] | LOCKING PLATE | BASBolt, Lock Superseded by part number: 81823525 |
| 35. | 82037652 | [1] | SEAL | FARAssy., Boot |
| 36. | 81877008 | [1] | ROD | BASBrake Control, 7.03" x M12 x 1.75 |
| 39. | PL | [1] | PROCURE LOCALLY | BASCotter Pin, 1/8" x 1" |
| 40. | 76260S36 | [1] | CLEVIS PIN,5/8" x 1 3/8" L | BASPIN, CLEVIS, 5/8" x 1 3/8" L Superseded by part number: 83928668 |
| 41. | 86505999 | [11] | BOLT,Hex, 5/8" - 11 x 2", Gr 5 | NHCap, HH, G5, 5/8"-11 x 2" |
| 42. | 86564282 | [1] | SHAFT | BASD65 |
| 42. | 82017334 | [1] | SHAFT | BASD65 Industrial, Years: -31-DEC-05 Superseded by part number: 87307076 |
| 42. | 87307076 | [1] | ARTICULATED AXLE SHAFT | BASShaft, D65 Industrial, Start Year: 01-JAN-06 |
| 43. | D4NN1107A | [14] | BOLT | FORTapered Shoulder, 3/4" - 10 UNC |
| 43. | 58741S36 | [14] | BOLT,Hex, 3/4"-10 x 2", G8 | FORHH, G8, 3/4"-10 x 2"; Use with 383953S2 flat washer Superseded by part number: F0NN3A343AA, 9635076 |
| 44. | 83958913 | [1] | SEAL,101.22mm ID x 135.2mm OD x 15.01mm Thk | BAS |
| 45. | 86516475 | [1] | ROLLER BEARING | WINCone, Roller Bearing, Outer Superseded by part number: 86627199 |
| 45. | 87307078 | [1] | BEARING ASSY,82.55 mm ID x 133.375 mm OD x 39.89 mm | BASCone, Roller Bearing, Outer, D65 Industrial, Start Year: 01-JAN-06 Superseded by part number: A50325 |
| 46. | 83417133 | [1] | O-RING,3.63mm Thk x 336.91mm ID | FOR13.50" ID x .139" Thk (Seal) |
| 47. | 87996 | [6] | BOLT,Hex, 1/2" - 13 x 4 1/2", Gr 5 | WIN |
| 48. | C5NN4194B | [1] | BLOCK | FORThrust (5.286, 6.667 Ratios) Superseded by part number: 81803367 |
| 48. | 83959624 | [1] | BLOCK | BASThrust (3.500, 4.111, 4.625 Ratios) |
| 49. | 80680 | [2] | LOCK WASHER,3/8 0.381 CST ZND | NHWASHER, LOCK, 3/8" |
| 50. | 88206 | [2] | BOLT,Hex, 3/8" - 16 x 1", Gr 5 | NH |
| 51. | 86579036 | [1] | SLEEVE,152.3mm ID x 203.45mm OD x 40.89mm L | BASSleeve, D65 Only |
| 52. | F0NN4N319AA | [1] | PLUG | BASD65I L/brakes Superseded by part number: 83991145 |
