神钢零件查询(4JB1) - ISUZU DIESEL ENGINE (1/06-12/07) (01-019) - OIL PIPE & FIXING PARTS Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
505 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VI8944348271 | [1] | PIPE | KOBPIPE ASM,OIL PUMP |
| 2. | VI5096230020 | [1] | O-RING | KOBPACKING,O-RING |
| 5. | VI8941293310 | [1] | PIPE ASM. ,OIL, INJ.PUMP | |
| 5. | VI8941701231 | [1] | PIPE | KOBPIPE ASM,OIL,INJ.PUMP Superseded by part number: VI8972329570 |
| 6. | VI8941293290 | [1] | PIPE ASH,OIL.GEAR CASE | |
| 6. | VI8943275641 | [1] | PIPE ASM,OIL,GEAR CASE | |
| 6. | VI8971397130 | [1] | PIPE ASM,OIL,GEAR CASE(96-9-) | |
| 6-1. | VI8941397471 | [1] | PIPE | KOBASM,OIL.GEAR CASE Superseded by part number: VI8971607060 |
| 6-1. | VI8944535481 | [1] | PIPE ASM,OIL,GEAR CASE(94-5-) | |
| 6-1. | VI8971607060 | [1] | PIPE | KOBPIPE ASM,OIL,GEAR CASE(96-6-) |
| 6-2. | VI8941701240 | [1] | PIPE ASM,OIL,GEAR CASE | |
| 6-3. | VI8971133361 | [1] | PIPE ASM,OIL,GEAR CASE | |
| 7. | VI8941077850 | [1] | B0LT,JOINT.M8 L28 | |
| 7. | VI5096750181 | [1] | BOLT | KOBB0LT,JOINT,M8 L20 |
| 8. | VI5096750321 | [1] | BOLT,JOINT,JET GEAR CASE | |
| 9. | VI9095720080 | [2] | GASKET | KOBPACKING,GEAR CASE |
| 10. | VI0500406120 | [1] | BRACKET | KOBBOLT,SEMS,OIL PIPE CLIP |
| 10. | VI0208010160 | [1] | BOLT,OIL PIPE CLIP FIX. | |
| 10. | VI0500408200 | [1] | BOLT | KOBBOLT,OIL PIPE CLIP FIX. Superseded by part number: VI0507408200 |
| 11. | VI0208010160 | [1] | BOLT,OIL PIPE CLIP FIX. | |
| 11. | VI9020408160 | [1] | BOLT,OIL PIPE FIX. | |
| 11. | VI0208008160 | [1] | SCREW | KOBBOLT,OIL PIPE FIX. Superseded by part number: 0208008160 |
| 11. | VI0500408200 | [1] | BOLT | KOBBOLT,OIL PIPE FIX.(94-4-) Superseded by part number: VI0507408200 |
| 12. | VI9091505100 | [1] | WASHER | KOBWASHER,SPR. Superseded by part number: VI1099853450 |
| 12. | VI9091505080 | [1] | WASHER | KOBWASHER,SPR. Superseded by part number: VI0915105080 |
| 13. | VI9091647080 | [1] | WASHER | KOBWASHER,PL.(94-4-) Superseded by part number: 87597736 |
| 17. | VI8941465820 | [1] | SCREW | KOBBOLT,EYE |
| 17. | VI8944541990 | [1] | BOLT | KOBBOLT,EYE(94-6-) Superseded by part number: VI5096750430 |
| 17. | VI8941719440 | [1] | BOLT,JOINT | |
| 18. | VI8971232950 | [1] | CONNECTOR,PIPE,GEAR CASE(95-2-) | |
| 19. | VI9095714080 | [4] | PACKING | KOBPACKING,JOINT BOLT Superseded by part number: 289808A1 |
| 20. | VI0208008120 | [1] | BOLT,CLIP | |
| 20. | VI0500408220 | [1] | BOLT | KOBBOLT, OIL PIPE |
| 21. | VI9091505080 | [1] | WASHER | KOBWASHER,SPR. Superseded by part number: VI0915105080 |
| 25. | VI0023114100 | [1] | HOSE,RUBBER,VAC.PUMP | |
| 26. | VI5097070253 | [2] | CLIP,RUBBER HOSE | |
| 26. | VI8971081020 | [2] | CLIP,RUBBER HOSE(94-3-) | |
| 27. | VI8970372482 | [1] | PIPE ASM,OIL,VAC.PUMP | |
| 28. | VI5096750240 | [1] | BOLT,EYE,OIL PIPE | |
| 29. | VI9095720080 | [2] | GASKET | KOBPACKING,EYE BOLT |
| 30. | VI9095720100 | [2] | SEAL | KOBPACKING,EYE BOLT |
