| 1. | VI8941701253 | [1] | WATER PUMP | KOBPUMP ASM,WATER Superseded by part number: VI8970285901 |
| 1-1. | VI8943359572 | [1] | PUMP ASM,WATER | |
| 1. | VI8944237531 | [1] | WATER PUMP | KOBPUMP ASM,WATER Superseded by part number: VI8972590181 |
| 1. | VI8943388480 | [1] | WATER PUMP | KOBPUMP ASM,WATER Superseded by part number: VI8972590181 |
| 2. | VI8970285900 | [1] | WATER PUMP | KOBPUMP KIT,WATER,W/GASKET Superseded by part number: VI8970285901 |
| 2. | VI8970213160 | [1] | PUMP KIT,WATER,W/GASKET | |
| 2. | NSS | [1] | NOT SOLD SEPARAT | CONPUMP KIT,WATER,W/GASKET |
| 3. | VI8970285970 | [1] | KIT | KOBREPAIR KIT,WATER PUMP |
| 3. | VI8943227940 | [1] | REPAIR KIT | KOBREPAIR KIT,WATER PUMP Superseded by part number: VI5878156590 |
| 5. | VI8941701270 | [1] | COVER | |
| 6. | VI8941701280 | [1] | PACKING | |
| 7. | VI8941147270 | [1] | IMPELLER | |
| 7. | VI8942501630 | [1] | IMPELLER | |
| 8. | VI8941105600 | [1] | BEARING | KOBUNIT BRG. Superseded by part number: VI8944219420 |
| 10. | VI8944223260 | [1] | OIL SEAL | KOBSEAL UNIT Superseded by part number: 8970686530 |
| 11. | VI5136420640 | [1] | CENTER | |
| 11. | VI8944520910 | [1] | COLLAR CLAMP | KOBCENTER |
| 12. | VI9136390010 | [1] | THROWER | |
| 13. | VI8941116150 | [1] | JOINT | |
| 14. | VI9098140141 | [1] | SET SCREW | |
| 15. | VI9091505080 | [1] | WASHER | KOBWASHER,SPR. Superseded by part number: VI0915105080 |
| 16. | VI9030658160 | [3] | SCREW | |
| 17. | VI5096050050 | [1] | PLUG | KOBPLUG |
| 18. | VI8944224290 | [1] | GASKET | KOB, Serial Range: packing,pump-f.plate Superseded by part number: VI8970955120 |
| 18. | VI8970955120 | [1] | GASKET | KOBPACKING,PUMP TO F.PLATE(94-11-) |
| 18. | VI8941780810 | [1] | GASKET | KOBPACKING,PUMP TO C.BLOCK Superseded by part number: VI8941780811 |
| 20. | VI5090000841 | [2] | BOLT | KOBBOLT,SEMS.PUMP.L=55 Superseded by part number: VI8941500451 |
| 20. | VI0500408400 | [1] | BOLT | KOBBOLT,SEMS,PUMP,L=40 |
| 20. | VI8942059861 | [2] | BOLT | KOBBOLT,SEMS,PUMP,L=65 |
| 21. | VI9041108220 | [2] | STUD | KOBSTUD,WATER PUMP FIX. |
| 21. | VI9041108400 | [3] | STUD | KOBSTUD,WATER PUMP FIX. |
| 22. | VI8942248290 | [2] | NUT | KOBNUT,WATER PUMP FIX |
| 22. | VI9091104080 | [3] | HANGER | KOBNUT,WATER PUMP FIX Superseded by part number: VI0911105080 |
| 23. | VI9091505080 | [3] | WASHER | KOBWASHER,SPR. Superseded by part number: VI0915105080 |
| 25. | VI5137130471 | [1] | PIPE,WATER OUTLET | |
| 25-3. | VI8942546011 | [1] | PIPE | KOBPIPE,WATER OUTLET |
| 25-5. | VI8943685870 | [1] | PIPE ASM.IWATER OUTLET | |
| 25. | VI9137130641 | [1] | PIPE,WATER OUTLET | |
| 25-2. | VI8941525950 | [1] | RIGID TUBE | KOBPIPE,WATER OUTLET Superseded by part number: VI8943685890 |
| 25-1. | VI9137130380 | [1] | RIGID TUBE | KOBPIPE,WATER OUTLET Superseded by part number: VI8971690151 |
| 25. | VI8971690150 | [1] | RIGID TUBE | KOBPIPE,WATER OUTLET(96-9-) Superseded by part number: VI8971690151 |
| 26. | VI8943622020 | [1] | GASKET | KOBPACKING,OUTLET PIPE Superseded by part number: VI8943656741 |
| 26. | VI8943656741 | [1] | GASKET | KOBPACKING,OUTLET PIPE Superseded by part number: 355244A1, VI8943622020 |
| 28. | VI0501408300 | [2] | SPECIAL BOLT | KOBbolt,sems.outlet pipe Superseded by part number: VI0506408300 |
| 29. | VI5096050050 | [1] | PLUG | KOBplug,water inlet pipe |
| 29. | VI8942149620 | [1] | THERMOSTAT | KOB Superseded by part number: VI8970898910 |
| 29. | VI8943825460 | [1] | THERMOSTAT | KOB |
| 30. | VI8970186640 | [1] | MOTOR HOUSING | KOBHOUSING ASM,THERMOSTAT |
| 30. | VI8941258513 | [1] | HOUSING ASM,THERMOSTAT | |
| 30. | VI8941258531 | [1] | HOUSING ASM,THERMOSTAT | |
| 30. | VI8944787042 | [1] | HOUSING ASM,THERMOSTAT | |
| 30. | VI8944288120 | [1] | HOUSING | KOBHOUSING ASM,THERMOSTAT |
| 30-1. | VI8941701292 | [1] | MOTOR HOUSING | KOBHOUSING ASM,THERMOSTAT Superseded by part number: VI8970186640 |
| 32. | VI8943288320 | [1] | HOSE | KOBRUBBER,BY PASS |
| 32-2. | VI8941096811 | [1] | HOSE | KOBHOSE,RUBBER,BY PASS ID=22 Superseded by part number: 8941096811 |
| 32-3. | VI0032161100 | [1] | HOSE,RUBBER,BY PASS | |
| 32. | VI5096050050 | [1] | PLUG | KOBPLUG,WATER OUTLET PIPE |
| 33. | VI8944138220 | [2] | CLIP | KOBCLIP,BY PASS HOSE Superseded by part number: VI8980383710 |
| 33. | VI9097150531 | [2] | CLIP | KOBclip,by pass hose |
| 34. | VI8943656750 | [1] | PACKING,HOUSING.THERMO | |
| 34. | VI8943656751 | [1] | GASKET | KOBPACKING,HOUSING,THERMO(95-12-) Superseded by part number: VI8972161560 |
| 34-1. | VI8941712940 | [1] | GASKET | KOBPACKING,HOUSING,THERMO Superseded by part number: VI8970908790 |
| 34-1. | VI8970908790 | [1] | GASKET | KOBPACKING,HOUSING.THERMO(94-11-) |
| 35. | VI0500408300 | [3] | BOLT | KOBBOLT,SEMS,HOUSING Superseded by part number: VI0505408300 |
| 35. | VI0501408300 | [2] | SPECIAL BOLT | KOBBOLT,OUTLET TO HSG Superseded by part number: VI0506408300 |
| 35. | VI0500408350 | [2] | BOLT | KOBBOLT,SEMS,HOUSING |
| 35. | VI0500408700 | [2] | BOLT | KOBBOLT,SEMS,HOUSING L=70 Superseded by part number: VI0505408700 |
| 35. | VI0500408200 | [3] | BOLT | KOBBOLT,SEMS,HOUSING Superseded by part number: VI0507408200 |
| 36. | VI8941493591 | [1] | PULLEY,COOLING FAN,D=130 | |
| 36. | VI8970369560 | [1] | PULLEY,COOLING FAN,D=122 | |
| 36. | VI8944273602 | [1] | PULLEY | KOBPULLEY,COOL FAN,D=130 9X8 |
| 37. | VI9891364230 | [1] | SPACER | KOBspacer,fan t=18.0 |
| 37. | VI9136420780 | [1] | SPACER | KOBSPACER,FAN T=32.0 |
| 37. | VI9136420790 | [1] | SPACER,FAN T=59.5 | |
| 37. | VI9136420761 | [1] | SPACER,FAN T=6.0 | |
| 37. | VI9136420770 | [1] | SPACER',FAN T=26.0 | |
| 38. | VI9096610050 | [1] | PLUG | KOBPLUG,OUTLET PIPE.PT3/8 |
| 38. | VI5096050050 | [2] | PLUG | KOBPLUG,THERMOSTAT HSG.PT3/8 |
| 38-1. | VI9096610050 | [1] | PLUG | KOBPLUG,THERMOSTAT HSG.M16 |
| 39. | VI9095713160 | [1] | O-RING | KOBPACKING,PLUG Superseded by part number: 355245A1 |
| 40. | VI5136603080 | [1] | FAN ASM,D=400, 6BLADE | |
| 40. | VI8970228100 | [1] | FAN ASM,D=380, 6BLADE | |
| 40. | VI8971342910 | [1] | FAN ASM,D=380,10BLADE | |
| 40-1. | VI8943426180 | [1] | FAN | KOBFAN ASM,D=450, 7BLADE Superseded by part number: VI8943426182 |
| 40-1. | VI5136603040 | [1] | FAN | KOBASM,D=400, 6BLADE Superseded by part number: VI5136603041 |
| 40-1. | VI8944080790 | [1] | FAN | KOBFAN ASM,D=380, 7BLADE |
| 40-1. | VI5136603150 | [1] | FAN ASM,D=380, 6BLADE PP | |
| 40-1. | VI8944331650 | [1] | FAN ASM,D=430. 6BLADE | |
| 40-1. | VI8944838940 | [1] | FAN ASM,D=430. 6BLADE | |
| 43. | VI0501408350 | [4] | BOLT | KOB, Serial Range: bolt,sems,fan-pulley Superseded by part number: VI0506408350 |
| 43. | VI0500408300 | [4] | BOLT | KOBBOLT,SEMS.FAN TO PULLEY Superseded by part number: VI0505408300 |
| 43. | VI0500408450 | [4] | BOLT | KOBBOLT,SEMS,FAN TO PULLEY |
| 43. | VI8942059881 | [4] | BOLT,FAN TO PULLEY L=95 | |
| 43. | VI0500408500 | [4] | BOLT,FAN TO PULLEY L=50 | |
| 43. | VI8942059861 | [4] | BOLT | KOBBOLT,FAN TO PULLEY L=65 |
| 43. | VI0500408600 | [4] | BOLT-FAN TO PULLEY L=60 | |
| 43. | VI8942059871 | [4] | BOLT,SEMS,FAN TO PULLEY | |
| 43. | VI0500408350 | [4] | BOLT | KOBBOLT,SEMS,FAN TO PULLEY |
| 43. | VI5090000841 | [4] | BOLT | KOBBOLT,SEMS,FAN TO PULLEY Superseded by part number: VI8941500451 |
| 43. | VI0501408500 | [4] | BOLT,SEMS,FAN TO PULLEY | |
| 43. | VI0500408000 | [4] | BOLT,FAN TO PULLEY L=100 | |
| 43-1. | VI0501408140 | [4] | BOLT,PULLEY FIX. L=14 | |
| 43-1. | VI0501408450 | [4] | BOLT | KOBBOLT,PULLEY FIX. L=45 Superseded by part number: VI0500408450 |
| 45. | VI5136711000 | [1] | BELT,COOL ING L=1130 | |
| 45. | VI1136712170 | [1] | BELT,COOLING L=1116 | |
| 45. | VI8942568000 | [1] | SPARE PART | HITBELT,COOLING L=1041 Superseded by part number: VI8944791010 |
| 45. | VI1136710110 | [1] | BELT,COOLING L=1080 | |
| 45. | VI8941293870 | [1] | BELT, TRANSMISSION | KOBBELT,COOLING L=1166 |
| 45. | VI8944076240 | [1] | BELT | KOBBELT,COOLING L=1041 Superseded by part number: VI8942403720 |
| 48. | VI8943163560 | [1] | PIPE,WATER.INLET | |
| 48. | VI8944340711 | [1] | PIPE,WATER.INLET | |
| 48. | VI8941337444 | [1] | PIPE | KOBPIPE,INLET,WATER Superseded by part number: 355229A1 |
| 48. | VI8944358780 | [1] | PIPE,INLET,WATER | |
| 48. | VI8970177750 | [1] | PIPE,INLET,WATER | |
| 48-1. | VI8944386170 | [1] | PIPE,INLET,WATER | |
| 50. | VI8941718980 | [1] | O-RING | KOBPACKING,INLET PIPE |
| 50. | VI8943656762 | [1] | GASKET | KOBPACKING,INLET PIPE Superseded by part number: 355227A1 |
| 51. | VI0500408220 | [2] | BOLT | KOBBOLT,SEMS INLET PIPE |
| 54. | VI8943668480 | [1] | PIPE ASM,WATER | |
| 55. | VI8943653810 | [1] | CAP,WEATER PIPE | |
| 56. | VI9099156422 | [1] | CLIP,CAP | |
| 57. | VI8943421751 | [1] | PIPE,WATER.OIL COOLER | |
| 57. | VI8970333920 | [1] | PIPEIWATER,OIL COOLER | |
| 57-1. | VI8944421572 | [1] | PIPE,WATER,OIL COOLER | |
| 57-2. | VI8944506270 | [1] | PIPE ASM,WATER.HD-COOLER | |
| 58. | VI0501408180 | [1] | BOLT | KOBBOLT,PIPE FIX. |
| 58-1. | VI0500408120 | [2] | BOLT,PIPE FIX. | |
| 58-2. | VI0500408140 | [1] | BOLT,PIPE FIX. | |
| 59. | VI5094400050 | [1] | NUT,WATER PIPE FIX. | |
| 60. | VI5095031181 | [1] | PIECE,DISTANCE | |
| 61. | VI8941744640 | [1] | HOSE,OIL COOLER OUT | |
| 62. | VI8970223140 | [1] | HOSE ,OIL COOLER IN | |
| 63. | VI9095612180 | [1] | O-RING | |
| 64. | VI8944138220 | [4] | CLIP | KOBCLIP,HOSE FIX. D=22 Superseded by part number: VI8980383710 |
| 64-2. | VI8943327860 | [1] | CLIP,HOSE | |
| 65. | VI8943628790 | [1] | HOSE,WATER PUMP TO PIPE | |
| 66. | VI8943423870 | [1] | HOSE,OIL COOLER IN | |
| 66. | VI8970402890 | [1] | HOSE,OIL COOLER IN | |
| 66. | VI0032162200 | [1] | HOSE,OIL COOLER IN | |
| 67. | VI8944421621 | [1] | HOSE,OIL COOLER OUT | |
| 67. | VI0032160900 | [1] | HOSE,OIL COOLER OUT | |
| 70. | VI8970179150 | [1] | RUBBER HOSE,HSG.-PIPE | |
| 71. | VI8970179160 | [1] | RUBBER HOSE,OIL COOLER | |
| 72. | VI8944535292 | [1] | BRACKET,PIPE ASM. | |
| 73. | VI1097010180 | [1] | CLIP,RUBBER HOSE FIX. D9 | |
| 73. | VI8970190830 | [1] | clip,rubber hose fix. dh | |
| 74. | VI0500408120 | [1] | bolt,clip fix. | |
| 74. | VI0500410200 | [1] | BOLT | KOBBOLT,CLIP FIX. Superseded by part number: VI0505410200 |
| 76. | VI8944146880 | [2] | CAP | KOBCAP,HEATER PIPE |
| 77. | VI9099156422 | [2] | CLIP,CAP | |
| 78. | VI9091105080 | [2] | HANGER | KOBNUT,OUTLET PIPE Superseded by part number: VI0911105080 |
| 79. | VI9091505080 | [2] | WASHER | KOBWASHER,SPR. Superseded by part number: VI0915105080 |
| 80. | VI8943660330 | [1] | WATER PIPE,TURBO FEED | |
| 81. | VI8944725830 | [1] | ADAPTER,T/C-W/PIPE | |
| 82. | VI8944725852 | [1] | PIPE,WATER,TURBO RETURN | |
| 83. | VI1096750810 | [2] | BOLT,EYE | |
| 84. | VI9095714120 | [4] | PACKING,WATER PIPE | |
| 85. | VI0500406120 | [1] | BRACKET | KOBBOLT,W/PIPE FIX. |
| 86. | VI8944725841 | [1] | PACKING,WATER PIPE | |
| 86. | VI9095714120 | [4] | PACKING,WATER | |
| 87. | VI8943406691 | [1] | HOSE,RUBBER.TURBO FEED | |
| 88. | VI8943252550 | [1] | HOSE,RUBBER.TURBO RETURN | |
| 89. | VI8942215190 | [4] | CLIP | KOBRUBBER HOSE |
