ZA4850003
|
[1] |
GATE ATTACHMENT - trip (Machinery Item, order 0101042)
|
|
| 1. |
ZA105896
|
[1] |
GUIDE
|
CAS
GATE ASSEMBLY - trip, 3 tine
|
| 2. |
ZA105536
|
[1] |
SHAFT
|
CAS
ASSEMBLY - stub
|
| 3. |
113-233
|
[3] |
BOLT,Hex, 3/8" - 16 x 1-3/4", Gr 5
|
CAS
- hex, 3/8"-16 NC x 1-3/4", grade 5 Superseded by part number: 9706689
|
| 4. |
120382
|
[3] |
LOCK WASHER,Helical Spring, 3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| 5. |
120377
|
[3] |
NUT,3/8" - 16, Gr 5
|
IH
Superseded by part number: 280136
|
| 6. |
ZA105533
|
[1] |
STRAP
|
CAS
- linkage
|
| 7. |
432-1216
|
[2] |
COTTER PIN,3/16" x 1"
|
CAS
Pin, Split (Cotter), 3/16" x 1"
|
| 8. |
495-11053
|
[3] |
WASHER,1/2", SAE
|
CAS
- flat, 17/32 x 1-1/16 x 5/64 inch (13 x 27 x 2 mm) Superseded by part number: 87364, 72187259
|
| 11. |
ZA105531
|
[1] |
LEVER
|
CAS
ARM - trip
|
| 12. |
26224R1
|
[1] |
BOLT,Short NK, 5/8"-11 x 5", G5
|
IH
- round head square neck, 5/8 NC x 5 inch Superseded by part number: 433-1080
|
| 13. |
9413960
|
[1] |
LOCK NUT,5/8"-11, GB
|
IH
NUT - hex lock, 5/8 inch NC Superseded by part number: 85700693
|
| 14. |
ZA105546
|
[1] |
BRACKET
|
CAS
- stop
|
| 15. |
598803R1
|
[2] |
CARRIAGE BOLT,Short NK, 5/16"-18 x 1", G5, Full Thd
|
IH
BOLT - round head square neck, 5/16 NC x 1 inch Superseded by part number: 88992
|
| 16. |
80681
|
[2] |
LOCK NUT,5/16"
|
NH
WASHER, LOCK, 5/16" Superseded by part number: 83990583
|
| 17. |
120376
|
[2] |
NUT,5/16"-18, G5
|
IH
Superseded by part number: 9635082
|
| 18. |
ZA105537
|
[1] |
ANGLE
|
CAS
BRACKET - trip arm
|
| 19. |
495967R1
|
[2] |
CARRIAGE BOLT,Short NK, 3/8"-16 x 1", G5, Full Thd
|
IH
BOLT - round head square neck, 3/8 NC x 1 inch Superseded by part number: 80280503
|
| 20. |
21403R1
|
[2] |
WASHER
|
IH
- flat 13/32 x 1 x 1/8 inch (10 x 25 x 3 mm) Superseded by part number: 87613212
|
| 23. |
97767C1
|
[1] |
SPRING
|
IH
- extension
|
| 24. |
ZA105547
|
[1] |
ANCHOR
|
CAS
STRAP - anchor, spring
|
| 25. |
550796R1
|
[1] |
CARRIAGE BOLT,3/8" - 16 x 1 1/4", Grade 5
|
IH
BOLT - hex, 3/8 NC x 1-1/4 inch Superseded by part number: 86508749
|
