神钢零件查询(4JB1) - ISUZU DIESEL ENGINE (1/06-12/07) (01-032) - ENGINE CONTROL & FIXING PARTS Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
789 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-1. | VI8944467761 | [1] | BRACKET, SOLENOID | |
| 1-2. | VI8944481913 | [1] | BRACKET,SOLENOID.W/M6X5 | |
| 1-4. | VI8943694521 | [1] | BRACKET,SOLENOID | |
| 2-1. | VI8944480030 | [1] | LINK ROD | |
| 2-1. | VI8944507240 | [1] | LINK ROD | |
| 3. | VI9091605050 | [2] | WASHER,PLAIN | |
| 4. | VI9091854040 | [2] | RING | KOBRING,SNAP,LINK ROD SET |
| 5. | VI0501406140 | [2] | BRACKET,SOLENOID,FIX | |
| 6. | VI0500410220 | [1] | BOLT | KOBBRKT.FIX. Superseded by part number: VI0505410200 |
| 6. | VI0500410350 | [3] | BOLT | KOBBOLT,BRKT.FIX. Superseded by part number: VI0505410350 |
| 6. | VI0500512250 | [2] | BOLT,BRKT.FIX. | |
| 6. | VI0500408320 | [1] | BOLT,BRKT.FIX. | |
| 6. | VI0208014250 | [1] | BOLT,BRKT.FIX. | |
| 7. | VI9091505060 | [2] | WASHER | KOBWASHER,SPR. |
| 8. | VI9091105060 | [2] | NUT,SOLENOID FIX. | |
| 9. | VI9091505140 | [1] | WASHER | KOBWASHER,SPR..BRKT.FIX. Superseded by part number: VI9091506140 |
| 10. | VI9091606060 | [2] | WASHER,PL,SOLENOID FIX. | |
| 15. | VI1232105970 | [1] | CABLE ASM,ENG.CONTROL(-94-10) | |
| 16. | VI9232196060 | [1] | CLEVIS,ENG.CONTROL(-94-10) | |
| 17. | VI9082236170 | [1] | PINPOINT(-94-10) | |
