沃尔沃零件查询4300 Charging oil-pump drive prod no 308044300 NoneNoneNoneAutodata Volvo online
广数供应链运营团队, 14 02月, 2025，浏览：
533 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 5. |
VOE7011014
|
[2] |
Ball bearing
|
HT-2899
|
| |
VOE4881081
|
[2] |
Roller bearing
|
HT 2900-
|
| 6. |
VOE914537
|
[1] |
Retaining ring
|
|
| 7. |
VOE4871523
|
[1] |
Spacer ring
|
|
| 8. |
VOE4715690
|
[1] |
Housing
|
|
| 9. |
VOE7019283
|
[2] |
Ball bearing
|
|
| 1. |
VOE4718040
|
[1] |
Shaft
|
|
| 10. |
VOE11036696
|
[1] |
Gear
|
|
| 11. |
VOE4715692
|
[1] |
Shaft
|
|
| 12. |
VOE4715693
|
[1] |
Socket
|
|
| 13. |
VOE914528
|
[1] |
Retaining ring
|
|
| 14. |
VOE914478
|
[0002] |
Snap ring
|
|
| 15. |
VOE914548
|
[0002] |
Retaining ring
|
|
| 16. |
VOE4715694
|
[0001] |
Washer
|
|
| 17. |
VOE925258
|
[0001] |
O-ring
|
|
| 18. |
VOE13970947
|
[0004] |
Hexagon screw
|
|
| 19. |
VOE941908
|
[0004] |
Spring washer
|
|
| 2. |
VOE11036417
|
[1] |
Screw
|
|
| 20. |
VOE950586
|
[0002] |
Pin
|
|
| 3. |
VOE941908
|
[1] |
Spring washer
|
|
| 4. |
VOE11036699
|
[1] |
Gear
|
|
