现代零件查询HDF15/18-5 4-SPOOL HYDRAULIC PIPING(TF-MAST)EPC Hyundai _现代Hyundai_工程机械

现代零件查询HDF15/18-5 4-SPOOL HYDRAULIC PIPING(TF-MAST)EPC Hyundai

广数供应链运营团队, 14 02月, 2025，浏览： 317 次

Pos.	Part No	Qty	Parts name	Comments
1.	P910-064041	[2]	HOSE ASSY-ORFS 0X0	TF370
1.	P910-064045	[2]	HOSE ASSY-ORFS 0X0	TF400
1.	P910-064049	[2]	HOSE ASSY-ORFS 0X0	TF430
1.	P910-064053	[2]	HOSE ASSY-ORFS 0X0	TF450
1.	P910-064055	[2]	HOSE ASSY-ORFS 0X0	TF470
1.	P910-064059	[2]	HOSE ASSY-ORFS 0X0	TF500
1.	P910-064067	[2]	HOSE ASSY-ORFS 0X0	TF550
1.	P910-064075	[2]	HOSE ASSY-ORFS 0X0	TF600
1.	P910-064082	[2]	HOSE ASSY-ORFS 0X0	TF650
1.	P910-064090	[2]	HOSE ASSY-ORFS 0X0	TF700
2.	P910-064037	[2]	HOSE ASSY-ORFS 0X0	TF370
2.	P910-064039	[2]	HOSE ASSY-ORFS 0X0	TF400
2.	P910-064041	[2]	HOSE ASSY-ORFS 0X0	TF430
2.	P910-064042	[2]	HOSE ASSY-ORFS 0X0	TF450
2.	P910-064044	[2]	HOSE ASSY-ORFS 0X0	TF470
2.	P910-064046	[2]	HOSE ASSY-ORFS 0X0	TF500
2.	P910-064049	[2]	HOSE ASSY-ORFS 0X0	TF550
2.	P910-064053	[2]	HOSE ASSY-ORFS 0X0	TF600
2.	P910-064057	[2]	HOSE ASSY-ORFS 0X0	TF650
2.	P910-064061	[2]	HOSE ASSY-ORFS 0X0	TF700
3.	P913-064018	[2]	HOSE ASSY-ORFS 0X0
4.	F42500010	[4]	PULLEY-HOSE	HDF15-5
4.	34FG-90201	[2]	PULLEY-HOSE	HDF15-5
4.	F42500010	[4]	PULLEY-HOSE	HDF18-5
4.	34FG-90201	[2]	PULLEY-HOSE	HDF18-5
5.	F42500020	[1]	PIN	HDF15-5
5.	F42500020	[1]	PIN	HDF18-5
6.	F42500030	[1]	PIN	HDF15-5
6.	34FG-90310	[2]	PIN-HOSE PULLEY	HDF15-5
6.	F42500030	[1]	PIN	HDF18-5
6.	34FG-90310	[2]	PIN-HOSE PULLEY	HDF18-5
7.	F42500040	[2]	COLLAR	HDF15-5
7.	F42500040	[2]	COLLAR	HDF18-5
8.	F42500050	[1]	SPACER	HDF15-5
8.	34FG-90330	[1]	SPACER	HDF15-5
8.	F42500050	[1]	SPACER	HDF18-5
8.	34FG-90330	[1]	SPACER	HDF18-5
9.	S017-100752	[1]	BOLT-HEX	HDF15-5
9.	S017-100602	[1]	BOLT-HEX	HDF15-5
9.	S017-100752	[1]	BOLT-HEX	HDF18-5
9.	S017-100602	[1]	BOLT-HEX	HDF18-5
10.	232110000	[1]	WASHER-PLAIN
11.	S411-100002	[1]	WASHER-SPRING
12.	FMC0300720B-01	[1]	BRACKET
13.	S017-101002	[1]	BOLT-HEX
14.	S403-102002	[1]	WASHER-PLAIN
15.	S275-100002	[1]	NUT-SELF LOCKING
16.	F53533010	[1]	COVER
17.	S035-081522	[1]	BOLT-W/WASHER
18.	31FG-80200	[4]	CONNECTOR-LONG	HDF15-5
18.	31FG-80210	[2]	CONNECTOR	HDF15-5
18.	31FG-80200	[4]	CONNECTOR-LONG	HDF18-5
18.	31FG-80210	[2]	CONNECTOR	HDF18-5
19.	31FG-80430	[8]	NUT-HEX	HDF15-5
19.	31FG-80430	[2]	NUT-HEX	HDF15-5
19.	31FG-80430	[8]	NUT-HEX	HDF18-5
19.	31FG-80430	[2]	NUT-HEX	HDF18-5
20.	33FJ-80131	[1]	PIPE WA
21.	X710-100103	[4]	CAP-ORFS
22.	S037-102022	[4]	BOLT-W/WASHER
23.	33FJ-80140	[1]	PIPE WA
24.	31FG-80410	[4]	CONNECTOR	HDF15-5
24.	31N5-30050	[4]	CONNECTOR-ORFS	HDF15-5
24.	31FG-80410	[4]	CONNECTOR	HDF18-5
24.	31N5-30050	[4]	CONNECTOR-ORFS	HDF18-5
25.	33FJ-80151	[2]	PIPE WA-ATTACH
26.	33FJ-80161	[2]	PIPE WA-ATTACH
27.	S017-120502	[1]	BOLT-HEX
28.	S411-120002	[1]	WASHER-SPRING
29.	S471-800162	[1]	PIN-SPRING
30.	33FG-90210	[1]	CLAMP-HOSE
31.	S035-082032	[2]	BOLT-W/WASHER
32.	6600363600	[1]	HOSE REEL-RH	TF370-470
32.	6600383800	[1]	HOSE REEL-RH	TF500-700
33.	P910-064029	[2]	HOSE ASSY-ORFS 0X0	TF370
33.	P910-064031	[2]	HOSE ASSY-ORFS 0X0	TF400
33.	P910-064033	[2]	HOSE ASSY-ORFS 0X0	TF430
33.	P910-064035	[2]	HOSE ASSY-ORFS 0X0	TF450
33.	P910-064036	[2]	HOSE ASSY-ORFS 0X0	TF470
33.	P910-064039	[2]	HOSE ASSY-ORFS 0X0	TF500
33.	P910-064042	[2]	HOSE ASSY-ORFS 0X0	TF550
33.	P910-064046	[2]	HOSE ASSY-ORFS 0X0	TF600
33.	P910-064050	[2]	HOSE ASSY-ORFS 0X0	TF650
33.	P910-064054	[2]	HOSE ASSY-ORFS 0X0	TF700
34.	S621-012001	[2]	O-RING
35.	X500-310002	[2]	CONNECTOR-ORFS
36.	S611-012001	[2]	O-RING 9/16-18UNF
37.	S017-120802	[2]	BOLT-HEX
38.	S441-120002	[2]	WASHER-HARDENED
39.	33FG-90310	[1]	BRACKET
40.	S037-102552	[2]	BOLT-W/WASHER
41.	33FJ-80170	[1]	ELBOW-90
42.	33FJ-80180	[1]	ELBOW-90,LONG
43.	S552-102370	[4]	CLAMP-BAND
99.	672563	[1]	SEAL KIT-H/REEL	NOT SHOWN
