久保田零件查询T11500 SEAT HOOD/BONNETEPC Kubota online
广数供应链运营团队, 14 02月, 2025，浏览：
231 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 010. |
3242072960
|
[1] |
SEAT
|
0.0000(lbs); 0.000
|
| 010. |
3508018400
|
[1] |
ASSY SEAT
|
0.0000(lbs); 0.000
|
| 010. |
3242072962
|
[1] |
SEAT
|
17.6000(lbs); 8.000
|
| 020. |
6706145920
|
[1] |
BRACKET
|
0.3960(lbs); 0.180
|
| 030. |
0112360816
|
[4] |
BOLT
|
0.0220(lbs); 0.010
|
| 040. |
6641645920
|
[1] |
STAY
|
0.0000(lbs); 0.000
|
| 040. |
6740145922
|
[1] |
STAY
|
0.1760(lbs); 0.080
|
| 050. |
0112360816
|
[2] |
BOLT
|
0.0220(lbs); 0.010
|
| 060. |
0512251045
|
[2] |
PIN JOINT
|
0.0638(lbs); 0.029
|
| 070. |
0551561000
|
[2] |
PIN SNAP
|
0.0044(lbs); 0.002
|
| 080. |
6659141540
|
[4] |
CUSHION
|
0.0220(lbs); 0.010
|
| 090. |
6659141550
|
[2] |
COLLAR
|
0.0440(lbs); 0.020
|
| 100. |
6641645930
|
[1] |
ASSY ADJUSTER SEAT
|
7.2600(lbs); 3.300
|
| 110. |
6706145943
|
[1] |
COMP ADJUSTER SEAT
|
5.2800(lbs); 2.400
|
| 120. |
6641645950
|
[1] |
SUPPORT ADJUSTER
|
0.3630(lbs); 0.165
|
| 130. |
6641645960
|
[1] |
SUPPORT ADJUSTER
|
0.9020(lbs); 0.410
|
| 140. |
0451260100
|
[4] |
WASHER SPRING
|
0.0044(lbs); 0.002
|
| 150. |
0201850100
|
[4] |
NUT
|
0.0242(lbs); 0.011
|
| 160. |
0112350825
|
[2] |
BOLT
|
0.0286(lbs); 0.013
|
| 170. |
0112350825
|
[2] |
BOLT
|
0.0286(lbs); 0.013
|
| 180. |
6706145970
|
[2] |
SPRING SEAT
|
0.2860(lbs); 0.130
|
| 190. |
0401560080
|
[2] |
WASHER PLAIN
|
0.0220(lbs); 0.010
|
| 200. |
0112350820
|
[2] |
BOLT
|
0.0242(lbs); 0.011
|
| 210. |
6630152820
|
[2] |
CAP SPRING
|
0.0880(lbs); 0.040
|
| 220. |
6641654950
|
[1] |
BRACKET SMV
|
0.0000(lbs); 0.000
|
| 220. |
6670454952
|
[1] |
BRACKET SMV
|
0.3300(lbs); 0.150
|
| 230. |
0105350616
|
[2] |
BOLT
|
0.0110(lbs); 0.005
|
| 240. |
0401350060
|
[2] |
WASHER PLAIN
|
0.0022(lbs); 0.001
|
| 250. |
0451260060
|
[2] |
WASHER SPRING
|
0.0022(lbs); 0.001
|
| 260. |
0201450060
|
[2] |
NUT
|
0.0044(lbs); 0.002
|
