凯斯零件查询(3650) - CASE IH ROUND TIE BALER (1/84-12/88) (22) - TAILGATE FRAME Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
160 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
ZA105137
|
[2] |
BUMPER
|
IH
- rubber (Prior to P.I.N. 001179)
|
| 2. |
106969R1
|
[4] |
WASHER
|
IH
- flat, 11/32 x 1-3/8 x 1/16 inch (8 x 34 x 1 mm) (Prior to P.I.N. 001179) Superseded by part number: 495-81119
|
| 3. |
ZA104429
|
[2] |
CABLE
|
IH
|
| 4. |
96326C1
|
[4] |
SLEEVE
|
IH
|
| 5. |
ZA105182
|
[1] |
SHIELD
|
IH
- rear left
|
| 6. |
ZA105196
|
[1] |
PRODUCT GRAPHIC
|
IH
DECAL - warning
|
| 7. |
ZA103821
|
[2] |
BUMPER
|
IH
- rubber
|
| 8. |
ZA105103
|
[2] |
BRACKET
|
IH
- bumper
|
| . . |
16897R1
|
[4] |
CARRIAGE BOLT,Short Nk, 5/16" - 18 x 3/4", Gr 2, Full Thd
|
IH
BOLT - round head, square neck, 5/16 NC x 3/4 inch Superseded by part number: 412-512
|
| 9. |
ZA740950
|
[2] |
DECAL
|
CAS
- shield warning Superseded by part number: ZA211862
|
| 10. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
EMBLEM - SMV
|
| 11. |
ZA104327
|
[1] |
HOUSING
|
IH
- rear
|
| 12. |
180175
|
[1] |
BOLT,Hex, 1/2" - 13 x 1 1/4", Gr 5
|
IH
- hex, 1/2 NC x 1-1/4 inch Superseded by part number: 113-417
|
| 13. |
120378
|
[1] |
NUT,Hex, 1/2" - 13, Gr 5
|
IH
NUT, 1/2"-13, G5 Superseded by part number: 280431
|
| 14. |
ZA105181
|
[1] |
SHIELD
|
IH
- rear right
|
| 16. |
ZA103937
|
[4] |
WASHER
|
IH
- retaining Superseded by part number: 1326407C1
|
| 17. |
ZA103138
|
[4] |
FASTENER
|
IH
|
| 18. |
1284374C1
|
[2] |
REFLECTOR
|
IH
- red
|
| 20. |
535329R1
|
[4] |
BUMPER
|
IH
- rubber (P.I.N. 001180 and after) Superseded by part number: L60224
|
| . . |
436525C1
|
[1] |
RIVET,Pop, 1/4" x 1/2"
|
IH
- mandrel, 6.3 x 12.7 mm
|
