约翰迪尔零件查询20``STD - ATTACHMENTS DISC BLADE 20`` HEAD FUTURE-2000 CARBIDE EARLIER DESIGN ( 62001 - 64149) 4544-017/10 [4544-017/10]EPC John Deere online
广数供应链运营团队, 14 02月, 2025，浏览：
530 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| |
---------
|
[1] |
DISC BLADE
|
|
| 2. |
---------
|
[1] |
DISC
|
|
| 3. |
700341200
|
[16] |
BOLT 1/2-13UNCX4 -
|
|
| 4. |
810669400
|
[16] |
LOCKNUT 1/2-13UNC -
|
|
| 5. |
700776100
|
[16] |
TOOTH - LATER DESIGN
|
|
| 6. |
-------
|
[16] |
TOOTH - EARLIER DESIGN
|
|
| |
|
|
NOTE 1:WHEN REPLACING EARLIER DESIGN
|
|
| |
|
|
TEETH WITH LATER DESIGN TEETH, ALL
|
|
| |
|
|
TEETH MUST BE REPLACED AT THE SAME
|
|
| |
|
|
TIME TO KEEP BLADE IN BALANCE
|
|
