凯斯零件查询(3650) - CASE IH ROUND TIE BALER (1/84-12/88) (36) - POWER TAKE OFF DRIVE SHAFT, WEASLER, P.I.N. 000756 THROUGH 001530 Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
437 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
96347C1
|
[1] |
JOINT
|
IH
ASSEMBLY - universal, tractor half (540 RPM)
|
| . . |
96346C1
|
[1] |
JOINT
|
IH
ASSEMBLY - universal, tractor half (1000 RPM)
|
| 1. |
660484R21
|
[1] |
FORK
|
IH
YOKE - 540 RPM Superseded by part number: 8803645
|
| 1. |
133317C1
|
[1] |
YOKE
|
IH
- 1000 RPM Superseded by part number: 1980759C1
|
| 2. |
480613R91
|
[1] |
KIT
|
IH
- cross Superseded by part number: 660116R91
|
| 3. |
661406R1
|
[1] |
LOCK WASHER,4.83mm ID x 18.542mm OD x 1.65mm Thk
|
IH
- x
|
| 4. |
455346R21
|
[1] |
PIN
|
IH
- quick lock, 540 RPM Superseded by part number: 237924A1
|
| 4. |
136015C1
|
[1] |
PIN
|
IH
- quick lock, 1000 RPM Superseded by part number: 237924A1
|
| 5. |
455347R1
|
[1] |
VALVE SPRING
|
IH
SPRING - lock pin Superseded by part number: 237924A1
|
| 6. |
80711
|
[1] |
LUBE NIPPLE,65 Degree, 1/8" NPT x 7/8" lg
|
NH
FITTING - grease, 1/8 pt 65 degree
|
| 7. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
SHAFT (Order complete assembly)
|
| 8. |
597559R1
|
[1] |
RETAINER
|
IH
RING - bearing retaining
|
| 9. |
96350C1
|
[1] |
SHIELD
|
IH
- 540 RPM
|
| 10. |
96335C1
|
[1] |
PRODUCT GRAPHIC
|
IH
DECAL - warning
|
| 11. |
96319C1
|
[1] |
DECAL
|
IH
- 540 RPM
|
| 11. |
96322C1
|
[1] |
PRODUCT GRAPHIC
|
IH
DECAL - 1000 RPM
|
| 12. |
1253795C1
|
[1] |
DECAL
|
CAS
- hitch advance
|
| 13. |
96348C1
|
[1] |
NYLON BEARING
|
IH
- plastic
|
| . . |
1336830C1
|
[1] |
JOINT
|
CAS
ASSEMBLY - universal, implement half
|
| 15. |
664179R1
|
[1] |
YOKE
|
IH
|
| 18. |
96349C1
|
[1] |
BEARING
|
IH
- plastic
|
| 20. |
96351C1
|
[1] |
SHIELD
|
IH
- rear
|
| 22. |
124934
|
[1] |
HOSE
|
IH
- hex jam, 1/2 inch NF Superseded by part number: 25-158, 25-158, NLS
|
| 23. |
38904K
|
[1] |
SET SCREW,1/2" - 20 x 1-9/16"
|
IH
SCREW - set, 1/2 NF x 1-3/16 inch
|
| 24. |
219-8
|
[2] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
NIPPLE, LUBE, , straight 1/4"-28 NPT x .54" lg Superseded by part number: 87414
|
