凯斯零件查询(3650) - CASE IH ROUND TIE BALER (1/84-12/88) (58) - PICKUP, PRIOR TO P.I.N. 001179 Case Agriculture

广数供应链运营团队, 14 02月, 2025，浏览： 732 次

Pos.	Part No	Qty	Parts name	Comments
35.	1281010C1	[2]	BUSHING	IH
36.	ZA105053	[1]	V-BELT,0.66" W x 78.52" L	IH Speed up (Used with sheave ZA105052) (Interchangeable with ZA104486) 0.66" W x 78.52" L
36.	ZA104486	[1]	V-BELT,0.66" W x 76.75" L	IH Slow down (Used with sheave ZA105052) (Interchangeable with ZA105053) 0.66" W x 76.75" L
37.	ZA104375	[1]	PULLEY	IH SHEAVE AND SPROCKET ASSEMBLY
38.	ZA104443	[1]	SHAFT	IH - pivot left
39.	152450R1	[1]	SNAP RING,#125, Ext	IH RING - external retaining, 1-5/32 inch Superseded by part number: 40974
40.	109461	[1]	LUBE NIPPLE,1/8"-27 x .66 lg	IH NIPPLE, LUBE, , PTF 1/8"-27 x .66 lg Superseded by part number: 80710
41.	ZA104464	[1]	STOP	IH - left Superseded by part number: 198025A1, 198026A1
42.	407211R1	[2]	CLIP	IH PIN - clip
43.	ZA104413	[1]	LOCKING PLATE	IH - lock
44.	ZA290043	[1]	SPRING	IH - extension
45.	ZA104461	[2]	BRACKET	IH - pickup mounting
46.	ZA100457	[1]	ANGLE	IH CLIP - angle
47.	ZA104503	[1]	STOP	IH - right Superseded by part number: 198026A1, 198025A1
48.	ZA762032	[1]	SPRING	IH
49.	ZA761517	[1]	PLUG	IH - spring
50.	120378	[1]	NUT,Hex, 1/2" - 13, Gr 5	IH NUT, 1/2"-13, G5 Superseded by part number: 280431
51.	480556C1	[1]	BOLT,Spcl, 1/2" - 13 x 8"	IH - hex, 1/2 NC x 8 inch
52.	ZA104441	[1]	SHAFT	IH - pivot right
53.	NLS	[2]	NO LONGER SERVICED	BAS - flat, 21/32 x 1-5/16 x 3/32 inch (16 x 33 x 2 mm)
54.	NSS	[1]	NOT SOLD SEPARAT	CON DECAL - grease (10 hours) (Order kit 1265869C93)
55.	ZA103666	[20]	DIVIDER	IH TOOTH DIVIDER - long
56.	ZA103667	[3]	DIVIDER	IH TOOTH DIVIDER - short
57.	ZA103715	[8]	ANGLE	IH - tooth support
. .	ZA104545	[1]	BRACKET	IH ASSEMBLY
