凯斯零件查询(3650) - CASE IH ROUND TIE BALER (1/84-12/88) (80) - BALE COUNTER Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
391 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
ZA105788
|
[1] |
PACKAGE
|
IH
KIT - bale counter
|
| 1. |
ZA103965
|
[1] |
COUNTER
|
IH
- bale
|
| 3. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
SCREW - slotted head, No. 5-44 x 5/16 inch (Order lever 656707R91)
|
| 4. |
ZA105135
|
[1] |
SPRING
|
IH
- flat
|
| 5. |
ZA105136
|
[1] |
CLIP
|
IH
- angle
|
| 6. |
159203
|
[4] |
SCREW,Cross Pan Hd, #4 - 40 x 1/2"
|
IH
- pan head cross recess, No. 4 x 1/2 inch Superseded by part number: 440-1048
|
| 7. |
21448R1
|
[2] |
WASHER
|
CAS
- flat, 11/32 x 7/8 x 3/32 inch (8 x 22 x 2 mm) Superseded by part number: 495-81253
|
| 8. |
180077
|
[2] |
BOLT,Hex, 5/16" - 18 x 3/4", Gr 5
|
IH
- hex, 5/16 NC x 3/4 inch Superseded by part number: 87872
|
| 9. |
7770
|
[2] |
NUT,Hex, 1/4 - 20, Cl 5
|
NH
- hex, 5/16 inch NC
|
