纽荷兰零件查询(BSD333H) - FORD 3 CYL DIESEL ENGINE (1/81-) (03T01) - STARTER MOTOR ASSEMBLY, DIESEL, 4-1/2" DIAMETER, 81/8-82 New Holland Constructuion

广数供应链运营团队, 14 02月, 2025，浏览： 1015 次

格莳国际 工程机械 重卡 农机 汽配
Pos.Part NoQtyParts nameComments
1. D8NN11000DA [1] STARTER MOTORFORStarting Motor Assy., 4-1/2" Dia., Includes: Ref. 2 thru 36, Years: 01-JAN-81-31-AUG-82 Superseded by part number: D9NN14N330AC, D8NN11000CD, E0NN14N330BA, E0NN14301CA
2. D2NN11005A [1] PROTECTING COVERFORArmature Assy., Includes: Ref. 3, Years: 01-JAN-81-31-AUG-82
3. D2NN11360A [1] PINFOR, Years: 01-JAN-81-31-AUG-82
4. 81829251 [1] PLATEAAssy., Brush End, Includes: Ref. 5 thru 10, Years: 01-JAN-81-31-AUG-82 Superseded by part number: D2NN11050A
5. D2NN11A022A [1] DOWELFOR, Years: 01-JAN-81-31-AUG-82
6. NSS [1] NOT SERVICED SEPARATELYCONBushing, Years: 01-JAN-81-31-AUG-82
7. 2701E11059A [4] SPRINGBAS, Years: 01-JAN-81-31-AUG-82
8. D2NN11055A [1] COMMUTATOR BRUSHFORBrush Set, Years: 01-JAN-81-31-AUG-82 Superseded by part number: 81829254
9. E4NN11A018BA [1] BRAKE SHOEBASKit, Shoe, Includes:, Years: 01-JAN-81-31-AUG-82 Superseded by part number: 83949350
10. C5NF11A020A [2] SPRINGFOR, Years: 01-JAN-81-31-AUG-82
11. C5NF11036B [1] WASHERFORMetal, Years: 01-JAN-81-31-AUG-82
12. C5NF11036D [1] THRUST WASHERFORWasher, Fabric, Years: 01-JAN-81-31-AUG-82
13. C5NF11415A [4] SCREW,Oval Hd, 3/8" - 16 x 1/2"FOR3/8"-16 x 1/2", Years: 01-JAN-81-31-AUG-82
14. D3NN11N020A [1] ELEC. TERMINAL PINFOR, Years: 01-JAN-81-31-AUG-82
15. C5NF11094B [2] WASHERFORInsulation, Years: 01-JAN-81-31-AUG-82
16. C5NF11107A [1] INSULATORFORNot Shown, Years: 01-JAN-81-31-AUG-82
17. C5NF11094A [3] WASHERFORInsulation, Years: 01-JAN-81-31-AUG-82
18. 80701 [3] WASHER,0.31" ID x 0.73" OD x 0.07" ThkNHNot Shown 1/4", Years: 01-JAN-81-31-AUG-82
. . 80682 [2] BEARING WASHER,1/4"PAWasher, Lock, 1/4", Years: 01-JAN-81-31-AUG-82
19. C5NF11A112A [2] NUTFOR1/4"-26, Years: 01-JAN-81-31-AUG-82
20. D2NN11082A [1] ROLLERFORCoil Assy. Includes: Ref. 21, Years: 01-JAN-81-31-AUG-82 Superseded by part number: 81829256
22. D1NN11N017A [1] GROMMETBAS, Years: 01-JAN-81-31-AUG-82 Superseded by part number: 81825453
23. D1NN11074A [1] INSULATORBAS, Years: 01-JAN-81-31-AUG-82
24. C5NF11036C [1] WASHERFOR.010 (.254mm), Years: 01-JAN-81-31-AUG-82
25. D2NN11395A [1] PLATEFORAssy., Includes: Ref. 26, Years: 01-JAN-81-31-AUG-82
27. D2NN11350C [1] DRIVE UNITFORDrive Assy., Years: 01-JAN-81-31-AUG-82
28. C5NF11166A [1] HOSE CLIPFORCollar, Years: 01-JAN-81-31-AUG-82
29. C5NF11223B [1] RETAINERFOR, Years: 01-JAN-81-31-AUG-82
30. D2NN11067A [1] LEVERFORAssy., Years: 01-JAN-81-31-AUG-82
31. D8NN11139AA [1] COTTER PINBASPin, Years: 01-JAN-81-31-AUG-82
32. D2NN11A115A [1] NUTBAS1/2"-26, Years: 01-JAN-81-31-AUG-82
33. D8NN11440AA [1] SEALFORGrommet, Years: 01-JAN-81-31-AUG-82
34. C9NN11N019A [1] STRAPFOR, Years: 01-JAN-81-31-AUG-82
36. 15896221 [2] NUT,Hex, M6, 5.20mm High, Cl 10ZED, Years: 01-JAN-81-31-AUG-82 Superseded by part number: 86500688
37. D8NN11130BA [1] STARTER MOTORFORHousing Assy., Includes: Ref. 38 & 39, Years: 01-JAN-81-31-AUG-82
39. D2NN11A022B [1] DOWELFOR, Years: 01-JAN-81-31-AUG-82
40. 80681 [2] BEARING WASHER,5/16"NHWasher, Lock, 5/16", Years: 01-JAN-81-31-AUG-82 Superseded by part number: 83990583
41. D2NN11A114A [2] WASHERFORTab, Years: 01-JAN-81-31-AUG-82
42. D2NN11091A [2] BOLTFOR1/4"-26 x 7.719, Years: 01-JAN-81-31-AUG-82
43. D2NN11126A [1] COVERFORBand Assy., Includes: Ref. 44 & 45, Years: 01-JAN-81-31-AUG-82
46. C9NN11N015A [1] GASKETFOR, Years: 01-JAN-81-31-AUG-82
47. D7NN11390A [1] SOLENOIDFORAssy., Includes: Ref. 46 & 47, Years: 01-JAN-81-31-AUG-82
48. C9NN11N018B [4] NUTFORHex, 8mm, Years: 01-JAN-81-31-AUG-82
50. D3NN11N054A [2] SCREW,Hex Wshr Hd, M6 x 20mmFORM6 x 1, Years: 01-JAN-81-31-AUG-82
. . E4NN11K175BA [1] KITBASStarter Motor Bushing, Incl. Ref. 6, 26 & 38 Superseded by part number: 83949368
