| 1. | D8NN11000CA | [1] | STARTER MOTOR | BASStarting Motor Assy., 5" Dia., Includes: Ref. 2 thru 52, Start Year: 01-SEP-85 Superseded by part number: D8NN11000CB |
| 2. | D0NN11005A | [1] | PROTECTING COVER | BASArmature Assy., Includes: Ref. 3, Start Year: 01-SEP-85 Superseded by part number: 81823250 |
| 3. | C5NF11360A | [1] | PIN | FOR, Start Year: 01-SEP-85 |
| 4. | D6NN11050A | [1] | PLATE | BASAssy., Includes: Ref. 5, Start Year: 01-SEP-85 |
| 5. | NSS | [1] | NOT SERVICED SEPARATELY | CONBearing, Start Year: 01-SEP-85 |
| 6. | E4NN11434BA | [1] | BRUSH HOLDER | BASHolder Assy., Includes: Ref. 7 & 8, Start Year: 01-SEP-85 Superseded by part number: 83949365 |
| 7. | 2701E11059A | [4] | SPRING | BAS, Start Year: 01-SEP-85 |
| 8. | C5NF11055B | [1] | COMMUTATOR BRUSH | FORBrush Assy., Insulated, pkg. of 2, Start Year: 01-SEP-85 Superseded by part number: 81812553 |
| 9. | D1NN11N051A | [2] | SCREW,1/4" - 28 x 7/8" | BAS, Start Year: 01-SEP-85 |
| 10. | D2NN11N052A | [2] | SEAL | BAS, Start Year: 01-SEP-85 |
| 11. | E4NN11A018BA | [1] | BRAKE SHOE | BASKit, Shoe, Includes: Ref. 12, Start Year: 01-SEP-85 Superseded by part number: 83949350 |
| 12. | C5NF11A020A | [2] | SPRING | FOR, Start Year: 01-SEP-85 |
| 13. | C5NF11036B | [1] | WASHER | FORMetal, Start Year: 01-SEP-85 |
| 14. | C5NF11036D | [1] | THRUST WASHER | FORWasher, Fabric, Start Year: 01-SEP-85 |
| 15. | C5NF11415A | [4] | SCREW,Oval Hd, 3/8" - 16 x 1/2" | FOR3/8"-16 x .50, Start Year: 01-SEP-85 |
| 16. | C9NN11N020A | [1] | TERMINAL CONNECTOR | FOR, Start Year: 01-SEP-85 |
| 17. | C5NF11094B | [2] | WASHER | FORInsulation, Start Year: 01-SEP-85 |
| 18. | C5NF11107A | [1] | INSULATOR | FOR, Start Year: 01-SEP-85 |
| 19. | C5NF11094A | [3] | WASHER | FORInsulation, Start Year: 01-SEP-85 |
| 20. | 80682 | [1] | BEARING WASHER,1/4" | PAWasher, Lock, 1/4", Start Year: 01-SEP-85 |
| 21. | C5NF11A112A | [3] | NUT | FORHex, 1/4"-26, Start Year: 01-SEP-85 |
| 22. | D1NN11082A | [1] | ROLLER | BASCoil Assy., Includes: Ref. 24, Start Year: 01-SEP-85 |
| 24. | D1NN11N017A | [1] | GROMMET | BAS, Start Year: 01-SEP-85 Superseded by part number: 81825453 |
| 25. | D1NN11074A | [1] | INSULATOR | BAS, Start Year: 01-SEP-85 |
| 26. | C5NF11036C | [1] | WASHER | FOR.010" (.254mm), Start Year: 01-SEP-85 |
| 27. | E4NN11395BA | [1] | PLATE | BASAssy., Includes: Ref. 28, Start Year: 01-SEP-85 |
| . . | D6NN11N074A | [1] | SEAL | BAS, Start Year: 01-SEP-85 |
| 29. | D2NN11350A | [1] | DRIVE UNIT | BASDrive Assy., 5" Dia., Start Year: 01-SEP-85 |
| 30. | C5NF11166A | [1] | HOSE CLIP | FORCollar, Start Year: 01-SEP-85 |
| 31. | C5NF11223B | [1] | RETAINER | FOR, Start Year: 01-SEP-85 |
| 32. | C5NF11067A | [1] | LEVER | FORAssy., Start Year: 01-SEP-85 |
| 33. | D8NN11139AA | [1] | COTTER PIN | BASPin, Start Year: 01-SEP-85 |
| 34. | D2NN11A115A | [1] | NUT | BAS1/2"-26, Start Year: 01-SEP-85 |
| 35. | D8NN11440AA | [1] | SEAL | FORGrommet, Start Year: 01-SEP-85 |
| 36. | C9NN11N019A | [1] | STRAP | FOR, Start Year: 01-SEP-85 |
| 38. | 15896221 | [2] | NUT,Hex, M6, 5.20mm High, Cl 10 | ZED, Start Year: 01-SEP-85 Superseded by part number: 86500688 |
| 39. | D8NN11130AA | [1] | SUMP | BASHousing Assy., Includes: Ref. 40 & 41, Start Year: 01-SEP-85 |
| 41. | D3NN11A022A | [1] | DOWEL | BAS, Start Year: 01-SEP-85 Superseded by part number: 81833783 |
| 42. | E231CL9 | [2] | WASHER | BAS, Start Year: 01-SEP-85 |
| 43. | 79DB11091AA | [2] | BOLT | FOR5/16"-24 x 7.7, Start Year: 01-SEP-85 |
| 44. | D6NN11N053A | [1] | SEAL | BAS, Start Year: 01-SEP-85 |
| 45. | D1NN11K150A | [1] | SEALING RING | BAS, Start Year: 01-SEP-85 |
| 46. | D7NN11390B | [1] | SOLENOID | BASAssy., Includes: Ref. 47 thru 51, Start Year: 01-SEP-85 |
| 47. | C7NN11A029A | [1] | PLATE | FOR, Start Year: 01-SEP-85 Superseded by part number: 81819256 |
| 48. | D0NN11N021A | [1] | LOCK WASHER | BASWasher, Lock, Start Year: 01-SEP-85 |
| 49. | C9NN11N018B | [1] | NUT | FORHex, 8mm, Start Year: 01-SEP-85 |
| . . | D6NN11N075A | [1] | SEAL | BAS, Start Year: 01-SEP-85 Superseded by part number: 83910899 |
| 52. | C9NN11N015A | [1] | GASKET | FOR, Start Year: 01-SEP-85 |
| . . | 9706689 | [1] | BOLT,Hex, 3/8" - 16 x 1 3/4", Gr 5 | PA, Start Year: 01-SEP-85 |
| . . | 88902 | [1] | NUT,3/8"-16 | NHNut, Lock, GC, 3/8"-16, Start Year: 01-SEP-85 |
| . . | 88011 | [2] | BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5 | NH, Start Year: 01-SEP-85 |
| . . | 34827S36 | [2] | LOCK WASHER | BASWasher, Lock, 3/8", Start Year: 01-SEP-85 |
| . . | C6JZ6404A | [1] | DECAL | FOR, Start Year: 01-SEP-85 |
| . . | E4NN11K175BA | [1] | KIT | BASStarter Motor Bushing, Incl. Ref. 5, 28 & 40 Superseded by part number: 83949368 |
