| 1. | D6NN10B376A | [1] | ALTERNATOR | BAS46 Amp., BSD 329, 332, 333, 333H, Includes: Ref. 2 thru 41, Years: 01-JAN-81-31-OCT-84 Superseded by part number: N802772S36, E3NN10B376AB |
| 2. | D4NN10353A | [1] | COVER | BAS, Years: 01-JAN-81-31-OCT-84 |
| 3. | D4NN10N317A | [1] | CLIP | BAS, Years: 01-JAN-81-31-OCT-84 |
| 4. | D4NN10N315B | [2] | SCREW,#8 - 32 x 1/2" | BAS, Years: 01-JAN-81-31-OCT-84 |
| 5. | D4NN10316A | [1] | VOLTAGE REGULATOR | BASRegulator, Includes: Ref. 6 thru 8, Years: 01-JAN-81-31-OCT-84 |
| 6. | NS | [1] | NOT SERVICED | BASConnector, Years: 01-JAN-81-31-OCT-84 |
| 7. | D4NN10N320A | [1] | SPACER | BAS, Years: 01-JAN-81-31-OCT-84 |
| 9. | D4NN10B363A | [1] | COVER | BASIncludes: Ref. 10 thru 13, Years: 01-JAN-81-31-OCT-84 Superseded by part number: 81845975 |
| 10. | D4NN10B341A | [1] | KIT | BASBrush, Years: 01-JAN-81-31-OCT-84 Superseded by part number: 81845965 |
| 11. | D4NN10N316A | [2] | SEAL | BAS.35 Square, Years: 01-JAN-81-31-OCT-84 |
| 13. | D4NN10N315A | [6] | SCREW,#4 - 20 x 3/8" | BAS#4-20 x 3/8", Years: 01-JAN-81-31-OCT-84 |
| 14. | D4NN10N321A | [1] | ELEC. TERMINAL PIN | BAS, Years: 01-JAN-81-31-OCT-84 |
| 15. | D4NN10304A | [1] | RECTIFIER | BAS, Years: 01-JAN-81-31-OCT-84 Superseded by part number: 81845910 |
| 16. | D4NN10315A | [1] | HYD CONNECTOR | BASConnector, Years: 01-JAN-81-31-OCT-84 |
| 17. | D4NN10N326A | [1] | SLEEVE | BAS, Years: 01-JAN-81-31-OCT-84 |
| 18. | 44711S36 | [2] | WASHER,#9, .208" x .469" x .065" Thk | WIN, Years: 01-JAN-81-31-OCT-84 |
| 19. | 9672521 | [1] | LOCK WASHER,Ext Tooth, #10 | WINWasher, Lock, Ext Tooth, #10, Years: 01-JAN-81-31-OCT-84 |
| 20. | 87825 | [1] | NUT,#10-32 | NHG2, #10-32, Years: 01-JAN-81-31-OCT-84 |
| 21. | D4NN10A396A | [3] | BOLT | BAS#10-32 x 2-15/16", Years: 01-JAN-81-31-OCT-84 Superseded by part number: 81846038 |
| 22. | D4NN10334A | [1] | SUMP | BASHousing Assy., Includes: Ref. 23 & 24, Years: 01-JAN-81-31-OCT-84 |
| 23. | D4NN10B310A | [1] | BUSHING | BAS, Years: 01-JAN-81-31-OCT-84 |
| 24. | 86511 | [1] | O-RING,0.07" Thk x 1.364" ID, -28, Cl 5, 75 Duro | WIN1.36" ID x .070" Thk, Years: 01-JAN-81-31-OCT-84 |
| 25. | RD4NN10368A | [1] | ALTERNATOR STATOR | BASStator, 46 Amp., Years: 01-JAN-81-31-OCT-84 |
| 26. | RD4NN10335A | [1] | ROTOR | BAS46 Amp., Includes: Ref. 27 thru 30, Years: 01-JAN-81-31-OCT-84 |
| 27. | D4NN10328A | [1] | RING | BAS, Years: 01-JAN-81-31-OCT-84 Superseded by part number: 81845958 |
| 28. | D4NN10A304A | [1] | BALL BEARING,15 mm ID x 35 mm OD x 11 mm | BASBearing, Years: 01-JAN-81-31-OCT-84 |
| 29. | D4NN10K310A | [1] | SEAL | BAS46 Amp., Years: 01-JAN-81-31-OCT-84 |
| 30. | 80496 | [1] | WOODRUFF KEY,#3, 1/8" x 1/2" | WINKey, Woodruff #3, 1/8" x 1/2", Years: 01-JAN-81-31-OCT-84 |
| 31. | D4NN10355B | [1] | HOUSING | BAS46 Amp., Includes: Ref. 32 thru 35, Years: 01-JAN-81-31-OCT-84 Superseded by part number: 81845974 |
| 32. | D4NN10A303A | [1] | BALL BEARING,15 mm ID x 42 mm OD x 13 mm | BASBearing, Years: 01-JAN-81-31-OCT-84 Superseded by part number: 28996640 |
| 33. | D4NN10N318A | [1] | BEARING | BASPlate, Years: 01-JAN-81-31-OCT-84 |
| 34. | D4NN10323A | [1] | RETAINER | BAS, Years: 01-JAN-81-31-OCT-84 |
| 35. | D4NN10N325A | [1] | RING | BAS1.65 O.D., Years: 01-JAN-81-31-OCT-84 |
| 36. | D4NN10380A | [1] | FAN | BAS46 Amp., Years: 01-JAN-81-31-OCT-84 Superseded by part number: 83900470 |
| 37. | D6NN10344A | [1] | PULLEY | BAS3.13 I.D., Years: 01-JAN-81-31-OCT-84 Superseded by part number: 83909617 |
| 38. | E3NN10N327AA | [1] | KIT | BASHardware, Years: 01-JAN-81-31-OCT-84 |
| 39. | 251333 | [1] | KIT | BASNut Assy., Years: 01-JAN-81-31-OCT-84 Superseded by part number: 2976592, 2976592, 83933669 |
| 40. | D4NN10N323A | [1] | DIODE | BASAssy., Includes: Ref. 41, Years: 01-JAN-81-31-OCT-84 Superseded by part number: 81845952 |
| 42. | D3NN10239A | [1] | BRACKET | BASAssy., Years: 01-JAN-81-31-OCT-84 Superseded by part number: 81837759 |
| 43. | 356189S36 | [2] | WASHER | FOR.39 x .75, Years: 01-JAN-81-31-OCT-84 Superseded by part number: 83933065 |
| 44. | 42997S100 | [2] | LOCK BOLT | BASCap, HH, G5, Self-Locking, 3/8"-16 x 7/8", Years: 01-JAN-81-31-OCT-84 Superseded by part number: 83925196 |
| 45. | 80681 | [2] | BEARING WASHER,5/16" | NHWasher, Lock, 5/16", Years: 01-JAN-81-31-OCT-84 Superseded by part number: 83990583 |
| 46. | 280736 | [2] | NUT,5/16"-18, GC | NHNUT, LOCK, 5/16"-18, GC, Years: 01-JAN-81-31-OCT-84 |
| 47. | 88275 | [2] | BOLT,Hex, 5/16" - 18 x 1 1/2", Gr 5 | NHScrew, Cap, HH, G5, 5/16"-18 x 1-1/2", Years: 01-JAN-81-31-OCT-84 |
| 48. | D8NN10145AA | [1] | SUPPORT | BASArm, Years: 01-JAN-81-31-OCT-84 Superseded by part number: 83919570 |
| 49. | 280161 | [1] | BOLT,Hex, 3/8" - 16 x 3", Gr 5 | NH, Years: 01-JAN-81-31-OCT-84 |
| 50. | 9635884 | [1] | BOLT,Hex, 5/16" - 18 1", Full Thd, Gr 5 | NH, Years: 01-JAN-81-31-OCT-84 |
| 51. | 351555S36 | [1] | LOCK WASHER | BASWasher, .33 x .88, Years: 01-JAN-81-31-OCT-84 Superseded by part number: 83974432 |
| 52. | D3NN10N311A | [1] | SENSOR | BASAssy., Years: 01-JAN-81-31-OCT-84 Superseded by part number: 82988248 |
| 53. | 87800127 | [1] | BELT | BAS1/2" x 55.26", Years: 01-JAN-81-31-OCT-84 Superseded by part number: 9604339 |
| 54. | D8NN10B381DA | [1] | SHIELD | FORGuard Assy., Years: 01-JAN-81-31-OCT-84 Superseded by part number: 83923925 |
