| 1. |
700117240
|
[1] |
STRUT
|
HFI
WA left
|
| 2. |
700117013
|
[1] |
STRAP
|
HFI
spring
|
| 3. |
700707651
|
[1] |
SPRING
|
CAS
compression
|
| 4. |
700117257
|
[2] |
SPACER
|
HFI
|
| 5. |
6524003
|
[1] |
SPACER
|
CAS
|
| 6. |
413-8128
|
[1] |
BOLT,Hex, 1/2" - 13 x 8", Gr 5
|
CAS
SCREW hex cap, 1/2"-13 x 8" Superseded by part number: 280831
|
| 7. |
705541
|
[1] |
WASHER,0.53" ID x 1.06" OD x 0.14" Thk
|
CAS
hardened plain, 1/2"
|
| 8. |
231-5148
|
[2] |
FLANGE NUT,Flg, USR, 1/2"-13
|
CAS
Superseded by part number: 72187069, 86512371
|
| 9. |
413-880
|
[1] |
BOLT,Hex, 1/2" - 13 x 5", Gr 5
|
CAS
SCREW hex cap, 1/2"-13 x 5" Superseded by part number: 87997
|
| 10. |
138-2000
|
[1] |
PIN,12.7mm OD x 50.8mm L, Coiled
|
CAS
|
| 11. |
413-624
|
[2] |
BOLT,Hex, 3/8" - 16 x 1-1/2", Gr 5
|
CAS
Superseded by part number: 72187209, 88044
|
| 12. |
492-11038
|
[2] |
LOCK WASHER,3/8"
|
CAS
Superseded by part number: 80680, 72187249
|
| 13. |
496-11041
|
[2] |
WASHER,13/32" x 13/16" x .065", HDN
|
CAS
hardened plain, 3/8" Superseded by part number: 86632588
|
| 14. |
700120645
|
[1] |
REINFORCEMENT
|
HFI
|
| 15. |
700120643
|
[1] |
DEFLECTOR
|
HFI
left
|
| 16. |
700117265
|
[1] |
WHEEL
|
L
ASSY. gathering, Includes: Ref. 23 Superseded by part number: 700727604
|
| 17. |
R53173
|
[2] |
ROLLER BEARING,0.75" ID x 0.655"
|
L
cone Superseded by part number: 412275
|
| 18. |
495-11066
|
[1] |
WASHER,5/8", SAE
|
CAS
narrow plain, 5/8" Superseded by part number: 87365
|
| 19. |
425-1210
|
[1] |
SLOTTED NUT,Hex, 5/8"-11, G5
|
CAS
|
| 20. |
700709032
|
[1] |
CAP
|
CAS
hub Superseded by part number: 48191
|
| 21. |
432-1016
|
[1] |
COTTER PIN,5/32" x 1"
|
CAS
5/32" x 1" Superseded by part number: 83903970
|
| 22. |
219-8
|
[1] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
Superseded by part number: 87414
|
| 23. |
651814R1
|
[2] |
BEARING CUP
|
IH
Superseded by part number: 36725
|
| 24. |
700117270
|
[1] |
SPINDLE
|
HFI
WA
|
| 25. |
495-11081
|
[1] |
WASHER,3/4", SAE
|
CAS
Superseded by part number: 87381
|
| 26. |
700117256
|
[1] |
SUPPORT
|
CAS
WA chain
|
