凯斯零件查询(8420) - CASE IH ROUND BALER (1/88-12/00) (03-08) - DEFLECTOR AND WINDGUARD ASSEMBLY Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
543 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700101849
|
[2] |
PLATE
|
HFI
shield
|
| 2. |
6212740
|
[2] |
SPACER
|
CAS
BUSHING
|
| 3. |
700101861
|
[1] |
SHIELD
|
HFI
left
|
| 4. |
433-612
|
[6] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 3/4", Gr 5
|
CAS
Superseded by part number: 280430
|
| 5. |
231-5146
|
[6] |
FLANGE NUT,3/8"-16
|
CAS
Superseded by part number: 72187068, 247780
|
| 6. |
700101867
|
[2] |
ROD
|
HFI
anchor
|
| 7. |
413-620
|
[1] |
BOLT,Hex, 3/8" - 16 x 1-1/4", Gr 5
|
CAS
Superseded by part number: 72187207, 88011
|
| 8. |
495-21044
|
[3] |
WASHER,3/8"
|
CAS
Superseded by part number: 87779090, 80702
|
| 9. |
492-11038
|
[1] |
LOCK WASHER,3/8"
|
CAS
Superseded by part number: 80680, 72187249
|
| 10. |
425-106
|
[1] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
| 11. |
700117261
|
[1] |
SEPARATOR
|
HFI
WA
|
| 12. |
700101862
|
[1] |
SHIELD
|
HFI
right
|
| 13. |
700117269
|
[1] |
STRAP
|
HFI
link
|
| 14. |
6255350
|
[1] |
SPACER
|
CAS
BUSHING
|
| 15. |
700106810
|
[1] |
ANGLE
|
HFI
|
| 16. |
451526
|
[1] |
THRUST WASHER
|
CAS
|
| 17. |
413-628
|
[1] |
BOLT,Hex, 3/8" - 16 x 1-3/4", Gr 5
|
CAS
Superseded by part number: 72187210, 9706689
|
| 18. |
230-4216
|
[1] |
LOCK NUT,3/8"-16, GA
|
CAS
Center Superseded by part number: 87039402
|
| 19. |
413-1020
|
[1] |
BOLT,Hex, 5/8" - 11 x 1-1/4", Gr 5
|
CAS
Superseded by part number: 280319
|
| 20. |
230-41110
|
[4] |
LOCK NUT,5/8"-11, GA
|
CAS
lock, hex top, 5/8"-11, GR/B Superseded by part number: 85700693
|
| 21. |
425-1010
|
[3] |
NUT,5/8"-11, G5
|
CAS
Superseded by part number: 280374
|
| 22. |
230-4115
|
[4] |
LOCK NUT,5/16"-18, GA
|
CAS
lock, hex top, 5/16"-18, GR/B Superseded by part number: 230-4145
|
| 23. |
700101845
|
[3] |
ROD
|
CAS
windguard
|
| 24. |
700101855
|
[1] |
CHANNEL
|
HFI
windguard
|
