凯斯零件查询(8420) - CASE IH ROUND BALER (1/88-12/00) (03-12) - DEFLECTOR CONTROL ASSEMBLY (RIGHT) Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
324 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
413-624
|
[1] |
BOLT,Hex, 3/8" - 16 x 1-1/2", Gr 5
|
CAS
Superseded by part number: 72187209, 88044
|
| 2. |
492-11038
|
[3] |
LOCK WASHER,3/8"
|
CAS
Superseded by part number: 80680, 72187249
|
| 3. |
425-106
|
[3] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
| 4. |
409-7616
|
[2] |
BOLT,Hex Flg, 3/8" - 16 x 1", Spcl
|
CAS
Superseded by part number: 9706726
|
| 5. |
231-5146
|
[3] |
FLANGE NUT,3/8"-16
|
CAS
Superseded by part number: 72187068, 247780
|
| 6. |
413-640
|
[1] |
BOLT,Hex, 3/8" - 16 x 2-1/2", Gr 5
|
CAS
Superseded by part number: 87936
|
| 7. |
451526
|
[2] |
THRUST WASHER
|
CAS
|
| 8. |
S120261
|
[1] |
PIN
|
CAS
COTTER wire hair, .148"
|
| 9. |
700117140
|
[1] |
MOUNTING PARTS
|
HFI
|
| 10. |
6255350
|
[1] |
SPACER
|
CAS
BUSHING
|
| 11. |
413-620
|
[1] |
BOLT,Hex, 3/8" - 16 x 1-1/4", Gr 5
|
CAS
Superseded by part number: 72187207, 88011
|
| 12. |
700117255
|
[1] |
LEVER
|
CAS
|
| 13. |
427-6106
|
[1] |
CLEVIS PIN,9.53mm OD x 26.92mm L
|
CAS
3/8" x 1" Superseded by part number: 510390
|
| 14. |
700117260
|
[1] |
BRACE
|
HFI
support, right
|
| 15. |
286476
|
[1] |
SPACER
|
CAS
|
| 16. |
409-7620
|
[1] |
BOLT,Hex Flg, 3/8" - 16 x 1 1/4", Spcl
|
CAS
Superseded by part number: 86512174
|
| 17. |
6212740
|
[1] |
SPACER
|
CAS
BUSHING
|
