神钢零件查询(4D31-T) - MITSUBISHI DIESEL ENGINE (1/88-12/06) (02-001) - WATER PUMP Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
548 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-9A. | VAME018099 | [1] | WATER PUMP | KOBWATER PUMP ASSY Superseded by part number: VAME993517 |
| 1. | VAME015042 | [1] | CASE, WATER PUMP | |
| 2-5, 10. | VAME999618 | [1] | REPAIR KIT | KOBWATER PUMP REPAIR KIT |
| 2. | VAME018095 | [1] | IMPELLER | KOBIMPELLER |
| 3. | VAME018140 | [1] | SHAFT, PUMP | |
| 4. | VAMH034026 | [1] | SEAL | KOBSEAL, UNIT |
| 5. | VAMH040037 | [2] | BEARING, BALL | |
| 6. | VA3164501900 | [1] | SPACER SPACER | SPACER SPACER |
| 6A. | VAME015047 | [1] | WASHER | |
| 7. | VA3164501800 | [1] | PISTON RING SET | KOBRING, SNAP |
| 8. | VAMF522228 | [1] | SNAP RING | KOBRING, SNAP 47 |
| 9. | VAME018141 | [1] | FLANGE | |
| 9A. | VAMF430124 | [1] | NUT 14 | |
| . . | VAMF450408 | [1] | WASHER | KOBWASHER, SPG 14 |
| 10. | VAMF520416 | [1] | O-RING | KOBO-RING 100 |
| 11. | VAMF140225 | [2] | BOLT | KOBBOLT, FLANGE 8 X 20 |
| 12. | VAMF140241 | [2] | BOLT | KOBBOLT, FLANGE 8 X 80 |
