| 1. |
230-4115
|
[4] |
LOCK NUT,5/16"-18, GA
|
CAS
lock, hex top, 5/16"-18, GR/B Superseded by part number: 230-4145
|
| 2. |
700117223
|
[1] |
GUIDE
|
HFI
BRACKET twine
|
| 3. |
7745003
|
[1] |
GUIDE
|
L
|
| 4. |
51200861
|
[1] |
U-BOLT
|
BRR
|
| 5. |
433-512
|
[2] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5
|
CAS
Superseded by part number: 280327
|
| 6. |
231-5145
|
[2] |
SERRATED NUT,Flg, USR, 5/16"-18
|
CAS
Superseded by part number: 72187067, 145458
|
| 7. |
413-436
|
[1] |
BOLT,Hex, 1/4" - 20 x 2-1/4", Gr 5
|
CAS
Superseded by part number: 87405
|
| 8. |
232-4114
|
[3] |
LOCK NUT,1/4"-20, GC
|
CAS
hex top, 1/4"-20, GR/B Superseded by part number: 280129
|
| 9. |
087312
|
[1] |
LINK
|
HFI
endlap
|
| 10. |
700101800
|
[1] |
SPRING-CHECK
|
CAS
STOP
|
| 11. |
700707665
|
[2] |
LARGE PLATE
|
IH
PLATE, LARGE SPRING leaf
|
| 12. |
413-410
|
[2] |
BOLT,Hex, 1/4" - 20 x 5/8", Gr 5
|
CAS
Superseded by part number: 280641
|
| 13. |
700117214
|
[1] |
ARM
|
L
WA twine
|
| 14. |
700101799
|
[1] |
SLIDE GUIDE
|
HFI
rope
|
| 15. |
413-840
|
[1] |
BOLT,Hex, 1/2" - 13 x 2-1/2", Gr 5
|
CAS
SCREW hex cap, 1/2"-13 x 2-1/2" Superseded by part number: 87972
|
| 16. |
705541
|
[3] |
WASHER,0.53" ID x 1.06" OD x 0.14" Thk
|
CAS
hardened plain, 1/2"
|
| 17. |
80679
|
[1] |
LOCK WASHER,1/20.507 CST ZND
|
NH
|
| 18. |
425-108
|
[1] |
NUT,1/2" - 13, Gr 5
|
CAS
Superseded by part number: 280431
|
| 19. |
161430C91
|
[1] |
PULLEY
|
IH
V-IDLER
|
| 20. |
413-828
|
[1] |
BOLT,Hex, 1/2" - 13 x 1-3/4", Gr 5
|
CAS
Superseded by part number: 9707516, 72187217
|
| 21. |
495-21056
|
[1] |
WASHER,1/2"
|
CAS
wide plain, 1/2" Superseded by part number: 72187265, 80700
|
| 22. |
230-4118
|
[1] |
LOCK NUT,1/2"-13, GA
|
CAS
lock, hex top, 1/2"-13, GR/B
|
| 23. |
700117139
|
[1] |
SUPPORT
|
HFI
shaft
|
| 24. |
700707910
|
[1] |
BOLT
|
CAS
U
|
| 25. |
52324
|
[1] |
BUSHING
|
CAS
machinery, narrow rim, 1-1/4" x 10 gauge Superseded by part number: 052324
|
| 26. |
700117220
|
[1] |
PIVOT
|
CAS
WA twine arm
|
| 27. |
219-90
|
[1] |
LUBE NIPPLE,45 Degree Elbow, 1/4" -28 NPTF
|
CAS
ZERK, 1/4"-28 x 45° Superseded by part number: 87569
|
| 28. |
7741952
|
[1] |
KNOB
|
HFI
rope
|
