沃尔沃零件查询4300 Automatic vehicle lubrication, frame 983814300 NoneNoneNoneAutodata Volvo online
广数供应链运营团队, 14 02月, 2025，浏览：
230 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1D. |
VOE955782
|
[0003] |
Hexagon nut
|
|
| 44. |
VOE4928754
|
[0001] |
Plast.tube Tuft
|
|
| 45. |
VOE4928738
|
[0001] |
Tube
|
|
| 46. |
VOE946234
|
[0001] |
Plastic pipe
|
L=2000MM
|
| 47. |
VOE7352421
|
[0001] |
Nipple
|
|
| 48. |
VOE351777
|
[0001] |
Fitting
|
|
| 49. |
VOE4787762
|
[0002] |
Clutch
|
|
| 50. |
VOE942006
|
[0001] |
Nipple
|
|
| 51. |
VOE956981
|
[0001] |
Fitting nut
|
|
| 52. |
VOE13956967
|
[0001] |
Ferrule
|
|
| 53. |
VOE4881440
|
[REQ] |
Cable tie
|
|
| 2. |
VOE4787670
|
[0001] |
Clutch
|
|
| 54. |
VOE952623
|
[REQ] |
Clamp
|
6,4
|
| |
VOE952624
|
[REQ] |
Clamp
|
7,9
|
| |
VOE952625
|
[REQ] |
Clamp
|
9,5
|
| |
VOE952626
|
[REQ] |
Clamp
|
11,1
|
| |
VOE952627
|
[REQ] |
Clamp
|
12,7
|
| |
VOE952628
|
[REQ] |
Clamp
|
14,3
|
| 55. |
|
[REQ] |
Bolt
|
|
| 56. |
|
|
Tensioner sleeve
|
|
| 57. |
|
|
Sealing cone
|
|
| 3. |
VOE955976
|
[0001] |
O-ring
|
|
| 4. |
VOE4787683
|
[0001] |
Clutch
|
|
| 5. |
VOE4787673
|
[0001] |
Fitting
|
|
| 1. |
VOE4787779
|
[0001] |
Pump unit
|
|
| 6. |
|
[0001] |
Nipple
|
|
| 7. |
|
[0001] |
Sensor
|
SEE GROUP 31
|
| 8. |
VOE4928736
|
[0001] |
Tube
|
|
| 9. |
VOE4787865
|
[0001] |
Clutch
|
|
| 10. |
VOE4787673
|
[0001] |
Fitting
|
|
| 11. |
VOE4787679
|
[0001] |
Bulkhead grommet
|
|
| 12. |
VOE957019
|
[0001] |
Hexagon nut
|
|
| 13. |
|
[0001] |
Hose
|
|
| 14. |
VOE4787679
|
[0001] |
Bulkhead grommet
|
|
| 15. |
VOE957019
|
[0001] |
Hexagon nut
|
|
| 1A. |
VOE13955295
|
[0003] |
Screw
|
|
| 16. |
VOE4787673
|
[0001] |
Fitting
|
|
| 17. |
VOE4787672
|
[0001] |
Nipple
|
|
| 18. |
VOE4928742
|
[0001] |
Tube
|
|
| 19. |
|
[0001] |
Contact
|
|
| 20. |
VOE4787655
|
[0001] |
Spacer
|
|
| 21. |
|
[0002] |
Bolt
|
|
| 22. |
VOE4787674
|
[0001] |
Screw
|
|
| 23. |
VOE13947281
|
[0005] |
Gasket
|
|
| 24. |
VOE4880480
|
[0002] |
Dosage valve
|
5
|
| 25. |
VOE4881186
|
[0002] |
Dosage valve
|
20
|
| 1B. |
VOE13955894
|
[0003] |
Washer
|
|
| 26. |
VOE4928755
|
[0001] |
Plast.tube Tuft
|
|
| 27. |
VOE11023781
|
[0004] |
L-connection
|
|
| 28. |
VOE4787669
|
[0008] |
Clutch
|
|
| 29. |
VOE4787732
|
[0001] |
Clutch
|
|
| 30. |
VOE4928737
|
[0001] |
Tube
|
|
| 31. |
VOE4787675
|
[0001] |
Clutch
|
|
| 32. |
|
[0001] |
Bolt
|
|
| 33. |
VOE4787672
|
[0001] |
Nipple
|
|
| 34. |
VOE4928741
|
[0001] |
Tube
|
|
| 35. |
|
[0001] |
Contact
|
|
| 1C. |
VOE13941907
|
[0003] |
Washer
|
|
| 36. |
VOE4787658
|
[0001] |
Spacer
|
|
| 37. |
|
[0002] |
Bolt
|
|
| 38. |
VOE4787674
|
[0001] |
Screw
|
|
| 39. |
VOE13947281
|
[0009] |
Gasket
|
|
| 40. |
VOE11023511
|
[0006] |
Dosage valve
|
10
|
| 41. |
VOE4881186
|
[0002] |
Dosage valve
|
20
|
| 42. |
VOE4928753
|
[0001] |
Plast.tube Tuft
|
|
| 43. |
|
[0001] |
Plastic pipe
|
|
| |
VOE949120
|
[0400] |
Tube
|
|
| |
VOE4880152
|
[0300] |
Guard hose
|
|
