神钢零件查询(4D31-T) - MITSUBISHI DIESEL ENGINE (1/88-12/06) (06-001) - EXHAUST PIPE Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
232 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VAME080206 | [1] | PIPE, EXH PIPE, EXH | PIPE, EXH PIPE, EXH |
| 2. | VAME080046 | [1] | PIPE | KOBPIPE, MUFFLER TAIL |
| 3. | VAMD050079 | [1] | GASKET | KOBGASKET |
| 5. | VAMH000185 | [3] | BOLT | KOBBOLT 10 X 18 |
| . . | VAMF450406 | [3] | WASHER | KOBWASHER, SPG 10 |
| 6-7. | VAME019882 | [1] | CLAMP | KOBCLAMP ASSY |
| 6. | VAME019856 | [1] | CLAMP | KOBCLAMP |
| 7. | VAMF101314 | [2] | SCREW | KOBBOLT 12 X 35 Superseded by part number: VAF103512035 |
| . . | VAMS446185 | [2] | NUT | KOBNUT, FLANGE 12 |
| 9-10. | VAME027314 | [1] | CLAMP | KOBClAMP ASSY |
| 9. | VAME027147 | [1] | CLAMP | KOBCLAMP |
| 10. | VAMF101314 | [2] | SCREW | KOBBOLT 12 X 35 Superseded by part number: VAF103512035 |
| 15. | NSS | [1] | NOT SOLD SEPARAT | CONMUFFLER |
| 16. | VAME017791 | [2] | BRACKET | KOBBRACKET, MUFFLER |
| 17. | VAMH000713 | [4] | BOLT | KOBBOLT, FLANGE 10 X 20 |
| 18. | VA3089251500 | [2] | U-BOLT | KOBU-BOLT |
| 19. | VAMF434104 | [8] | NUT | KOBNUT, FLANGE 8 |
