神钢零件查询(4D31-T) - MITSUBISHI DIESEL ENGINE (1/88-12/06) (08-004) - LINER AND PISTON KIT Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
742 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-6. | VAME999869 | [1] | SLEEVE CYLINDER | KOBSLEEVE & PISTON KIT, ONE MODEL 4D31T |
| 1. | VAME011626 | [4] | SLEEVE CYLINDER | KOBSLEEVE, CYL STD |
| 2. | VAME012858 | [4] | PISTON | KOBPISTON STD |
| 3. | VAME999783 | [1] | PISTON RINGS KIT | KOBPISTON RING SET, ONE MODEL STD Superseded by part number: VAME997398 |
| 4. | VAME012009 | [4] | PISTON PIN | KOBPIN, PISTON |
| 5. | VAME012061 | [8] | SNAP RING | KOBRING, SNAP Superseded by part number: VAME015917 |
| 6. | VAME012234 | [4] | BUSHING | KOBBUSHING, CONN-ROD |
