现代零件查询HDF20/25/30-5 LIFT CYLINDER(TF-MAST,HDF30-5)EPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
1032 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
33FG-07100
|
[2] |
CYLINDER ASSY
|
|
| . |
33FG-07101
|
[2] |
CYLINDER ASSY
|
|
| . |
33FG-07110
|
[2] |
CYLINDER ASSY
|
|
| . |
33FG-07111
|
[2] |
CYLINDER ASSY
|
|
| . |
33FG-07120
|
[2] |
CYLINDER ASSY
|
|
| . |
33FG-07121
|
[2] |
CYLINDER ASSY
|
|
| . |
33FG-07130
|
[2] |
CYLINDER ASSY
|
|
| . |
33FG-07131
|
[2] |
CYLINDER ASSY
|
|
| . |
33FG-07140
|
[2] |
CYLINDER ASSY
|
|
| . |
33FG-07141
|
[2] |
CYLINDER ASSY
|
|
| . |
33FG-07150
|
[2] |
CYLINDER ASSY
|
|
| . |
33FG-07151
|
[2] |
CYLINDER ASSY
|
|
| . |
33FG-07160
|
[2] |
CYLINDER ASSY
|
|
| . |
33FG-07161
|
[2] |
CYLINDER ASSY
|
|
| . |
33FG-07170
|
[2] |
CYLINDER ASSY
|
|
| . |
33FG-07171
|
[2] |
CYLINDER ASSY
|
|
| . |
33FG-07180
|
[2] |
CYLINDER ASSY
|
|
| . |
33FG-07181
|
[2] |
CYLINDER ASSY
|
|
| . |
33FG-07190
|
[2] |
CYLINDER ASSY
|
|
| . |
33FG-07191
|
[2] |
CYLINDER ASSY
|
|
| 1. |
31Y3-18090
|
[1] |
TUBE ASSY
|
|
| 1. |
31Y3-18100
|
[1] |
TUBE ASSY
|
|
| 1. |
31Y3-18110
|
[1] |
TUBE ASSY
|
|
| 1. |
31Y3-18120
|
[1] |
TUBE ASSY
|
|
| 1. |
31Y3-18130
|
[1] |
TUBE ASSY
|
|
| 1. |
31Y3-18140
|
[1] |
TUBE ASSY
|
|
| 1. |
31Y3-18150
|
[1] |
TUBE ASSY
|
|
| 1. |
31Y3-18160
|
[1] |
TUBE ASSY
|
|
| 1. |
31Y3-19140
|
[1] |
TUBE ASSY
|
|
| 1. |
31Y3-19150
|
[1] |
TUBE ASSY
|
|
| 2. |
31Y3-18180
|
[1] |
ROD
|
|
| 2. |
31Y3-18190
|
[1] |
ROD
|
|
| 2. |
31Y3-18200
|
[1] |
ROD
|
|
| 2. |
31Y3-18210
|
[1] |
ROD
|
|
| 2. |
31Y3-18220
|
[1] |
ROD
|
|
| 2. |
31Y3-18230
|
[1] |
ROD
|
|
| 2. |
31Y3-18240
|
[1] |
ROD
|
|
| 2. |
31Y3-18250
|
[1] |
ROD
|
|
| 2. |
31Y3-19160
|
[1] |
ROD
|
|
| 2. |
31Y3-19170
|
[1] |
ROD
|
|
| 3. |
31Y3-18310
|
[1] |
PISTON
|
|
| K4. |
Y400-055000
|
[1] |
SEAL-PISTON
|
|
| K5. |
Y180-045020
|
[1] |
RING-BACK UP
|
|
| K6. |
Y310-055100
|
[1] |
RING-WEAR
|
|
| 7. |
31YC-99G20
|
[1] |
RING-RETAINING
|
|
| 8. |
31YC-99F60
|
[1] |
SEAL-CUSHION
|
|
| 9. |
31YC-99F70
|
[1] |
RING-RETAINING
|
|
| 10. |
31Y3-18270
|
[1] |
SPACER
|
|
| 10. |
31Y3-18271
|
[1] |
SPACER
|
|
| 10. |
31Y3-17810
|
[1] |
SPACER
|
|
| 10. |
31Y3-17811
|
[1] |
SPACER
|
|
| 10. |
31Y3-18280
|
[1] |
SPACER
|
|
| 10. |
31Y3-18281
|
[1] |
SPACER
|
|
| 10. |
31Y3-18290
|
[1] |
SPACER
|
|
| 10. |
31Y3-18291
|
[1] |
SPACER
|
|
| 11. |
S632-040004
|
[1] |
O-RING
|
|
| 12. |
31Y3-17850
|
[1] |
GUIDE
|
|
| 13. |
S731-045030
|
[1] |
BUSHING-DU
|
|
| 14. |
31Y3-17840
|
[1] |
GLAND
|
|
| K15. |
Y200-045011
|
[1] |
SEAL-ROD
|
|
| K16. |
Y120-045011
|
[1] |
WIPER-DUST
|
|
| K17. |
S632-060004
|
[1] |
O-RING
|
|
| K. |
31Y3-18760
|
[1] |
SEAL KIT
|
|
